Requirements
2
REQUIREMENTS
Site Requirements
Ensure that the site is ready:
The iSTAR Ultra installation must be performed by a certified installer.
The iSTAR Ultra must be installed and wired according to local and national
regulations.
All ACM wiring must be shielded.
All Control Units of the iSTAR Ultra must be installed in a restricted access,
protected area.
Non-limited power supply lines must maintain (1/2 inch (1.3 cm)) spacing
from limited power supply lines and other signaling lines. Secure lines must
be installed in accordance to local and national electric codes.
The site must be approved and all wiring must comply with UL requirements
and other codes, as appropriate. Installation shall be in accordance with the
National Electric Code, ANSI/NFPA 70-1993.
All preliminary site work is complete.
System power needs to be 12 Vdc. Appropriate circuit breakers must be
accessible. Power supplies must be listed to UL-603 and UL-294.
The system power circuit breaker must only be assessable by Authorized
Personal.
The site is clean and free of dust or other contaminants.
Ensure that the mounting site is ready to accommodate the iSTAR
dimensions.
iSTAR Ultra Wall Mount
Dimensions
Table 1 lists the iSTAR Ultra Cabinet Wall Mount Dimensions
Table 1. Cabinet (Wall Mount Dimensions)
Item Dimension/Location
Weight 26.5 lb (12.02 kg)
Height 21.5 in. (54.61 cm)
Width 25 in. (63.5 cm)
Depth 5 in. (12.7 cm)
Upper Mounting
Holes
10 in. (22.86 cm) center to center to center. The outer two mount holes
are keyhole type.
Bottom three
Mounting Holes
Directly below the upper mount holes.
