If an external RCD is required by local regulations, check which type of RCD is required
for the relevant electric code. Install the residual-current device (RCD) in accordance
with the applicable local standards and directives. SolarEdge recommends using a type-
A RCD. The recommended RCD value is 100 mA or 300 mA unless a lower value is
required by the specific local electric codes. When required by local regulations, the use
of an RCD type B is permitted.
NOTE
For multiple inverters, an RCD per inverter is required.
In installations where the local electric code requires an RCD with a lower leakage
setting, the discharge current might result in nuisance tripping of the external RCD. The
following steps are recommended to avoid nuisance tripping of the external RCD:
Select the appropriate RCD for correct operation of the installation: An RCD with a
rating of 30 mA may actually trip at a leakage as low as 15 mA (according to IEC
61008). High quality RCDs will typically trip at a value closer to their rating.
Configure the trip voltage of the inverter's internal RCD to a lower value than the trip
current of the external RCD. The internal RCD will trip if the current is higher than
the allowed current, but because the internal inverter RCD automatically resets when
the residual currents are low it saves the manual reset.
For detailed information, refer to the
RCD Selection for SolarEdge
Inverters Application Note
, available on the SolarEdge website at
http://www.solaredge.com/sites/default/files/application_note_ground_
fault_rcd.pdf.
Chapter 3: Installing the Inverter 29
StorEdge Three Phase Inverter MAN-01-00648-1.3
