111
Parameter Unit Germany Spain
≤ 13.8kVA > 13.8kVA > 30kVA
VDE
0126-1-1
Medium
voltage
Pac max SM10MT2 W 10000 10000 10000 10000 10000 10000
Pac max SM13MT2/3 W 13000 13000 13000 13000 13000 13000
Pac max SM15MT2/3 W 15000 15000 15000 15000 15000 15000
Iac max SM8MT2 A 12 12 12 12 12 12
Iac max SM10MT2 A 16 16 16 16 16 16
Iac max SM13MT2/3 A 20 20 20 20 20 20
Iac max SM15MT2/3 A 22 22 22 22 22 22
Parameter Unit Italy France Belgium Czech
Republic
Guida Con-
nessioni
CEI 0-21
Medium
voltage
Vac min 1 V 184 0 0 184 196 207
t Vac min 1 ms 200 0 0 200 1500 500
Vac max 1 V 276 0 0 264 264 253
t Vac max 1 ms 100 0 0 200 120 500
Vac min 2 V 0 0 0 0 115 184
t Vac min 2 ms 0 0 0 0 120 100
Vac max 2 V 0 0 0 0 0 276
t Vac max 2 ms 0 0 0 0 0 100
Vac 10 min max V 0 0 0 253 253 0
Monit. ext. input On/Off - - - - - -
f min 1 Hz 49.7 0 0 47.5 47.5 49.8
t f min 1 ms 100 0 0 200 120 500
f max 1 Hz 50.3 0 0 50.2 50.5 50.2
t f max 1 ms 100 0 0 200 120 500
f min 2 Hz 0 0 0 0 0 49.5
t f min 2 ms 0 0 0 0 0 100
f max 2 Hz 0 0 0 0 0 0
t f max 2 ms 0 0 0 0 0 0
df/dt max Hz/s 0 0 0 0 0 0
Ierr max mA 300 300 300 300 300 300
Iac mean max mA 0.5% of
Iacmax
0.5% of
Iacmax
1000 1000 1% of
Iacmax
1000
Restart delay s 0 0 0 0 0 0
Mains check On/Off Off On On On On On
- Vac MC max V 280 253 253 264 253 253
- Vac MC min V 161 196 196 184 196 207
- f MC max Hz 55 50.1 50.1 50.2 50.5 50.2
- f MC min Hz 45 49.9 49.9 47.5 47.5 49.8
- t MC monitoring s 0 300 300 30 30 30
Island Detection On/Off On Off Off On On On
Soft Start W/s 0 30 30 0 0 0
Pac progression %/min 0 0 0 0 0 0
P(f)-Mode On/Off - On On - - -
- f start Hz - 50.3 50.3 - - -
- f stop Hz - 50.1 50.1 - - -
- Reduction %/Hz - 83 83 - - -
- Re-increase %/min - - - - - -
Q-Mode Off
cos(φ)(Pac)
Off Off Off Off
