SolarMax 10MT2 - Page 53

112
en
Parameter Unit Italy France Belgium Czech
Republic
Guida Con-
nessioni
CEI 0-21
Medium
voltage
- Vac Lock On/Off - On - - - -
- Vac Lock-In V - 242 - - - -
- Vac Lock-Out V - 218 - - - -
FRT On/Off - - - - - -
- K factor - - - - - -
S max SM8MT2 VA 8000 8000 8000 8000 8000 8000
S max SM10MT2 VA 10000 10000 10000 10000 10000 10000
S max SM13MT2/3 VA 13000 13000 13000 13000 13000 13000
S max SM15MT2/3 VA 15000 15000 15000 15000 15000 15000
Pac max SM8MT2 W 8000 8000 8000 8000 8000 8000
Pac max SM10MT2 W 10000 10000 10000 10000 10000 10000
Pac max SM13MT2/3 W 13000 13000 13000 13000 13000 13000
Pac max SM15MT2/3 W 15000 15000 15000 15000 15000 15000
Iac max SM8MT2 A 12 12 12 12 12 12
Iac max SM10MT2 A 16 16 16 16 16 16
Iac max SM13MT2/3 A 20 20 20 20 20 20
Iac max SM15MT2/3 A 22 22 22 22 22 22
Parameter Unit Greece Greece Portugal Great
Britain
Switzerland Bulgaria
Mainland Islands
Vac min 1 V 184 184 196 212 184 184
t Vac min 1 ms 500 500 1500 2500 200 200
Vac max 1 V 264 264 264 259 264 264
t Vac max 1 ms 500 500 200 1000 200 200
Vac min 2 V 0 0 0 196 0 0
t Vac min 2 ms 0 0 0 500 0 0
Vac max 2 V 0 0 0 271 0 0
t Vac max 2 ms 0 0 0 500 0 0
Vac 10 min max V 253 253 253 0 253 253
Monit. ext. input On/Off - - - - - -
f min 1 Hz 49.5 47.5 47 47.5 47.5 47.5
t f min 1 ms 500 500 500 20000 200 200
f max 1 Hz 50.5 51 51 51.5 50.2 50.2
t f max 1 ms 500 500 500 90000 200 200
f min 2 Hz 0 0 0 47 0 0
t f min 2 ms 0 0 0 500 0 0
f max 2 Hz 0 0 0 52 0 0
t f max 2 ms 0 0 0 500 0 0
df/dt max Hz/s 0 0 0 0 0 0
Ierr max mA 300 300 300 300 300 300
Iac mean max mA 0.5% of
Iacmax
0.5% of
Iacmax
1000 0.25% of
Iacmax
1000 1000
Restart delay s 0 0 0 0 0 0
Mains check On/Off On On On On On On
- Vac MC max V 264 264 264 259 264 264
- Vac MC min V 184 184 196 212 184 184
- f MC max Hz 50.5 50.5 51 51.5 50.2 50.2
- f MC min Hz 49.5 49.5 47 47.5 47.5 47.5
