10.2.3 Failures
Status LED: orange
Status message Cause Steps
Vdc too high The DC input voltage of the
inverter is too high.
Immediately disconnect the DC
insulation switch.
Check module con guration.
Ierr too high The DC leakage current has
exceeded the admissible abso-
lute limit value lerr max.
Check the PV generator.
No mains There is no mains voltage Check the AC feed line.
Frequency too high The mains frequency is outside
of the f max 1 or f max 2 limit
values.
If this problem continues to
occur, contact the responsible
grid operator.
Frequency too low The mains frequency is outside
of the f min 1 or f min 2 limit
values.
Mains error Stand-alone operation was
detected
Vac too high The mains voltage is outside of
the Vac°max°1 or Vac°max°2
limit values.
Vac too low The mains voltage is outside
of the Vac°min°1 or Vac°min°2
limit values.
Uac 10min too high
The maximum 10-minute
average value of the mains
voltage (Vac 10 min max.) is
too high.
df/dt too high The change in the mains
frequency per second has
exceeded the maximum
admissible value df/dt max.
Insulation fault DC The insulation resistance of the
PV generator against earth is
too low.
Check the PV generator.
Phase and neutral conductor
are interchanged.
Connect phase and neutral
conductor in the AC coupling
connector correctly.
