SM 2000S SM 3000S SM 4200S SM 6000S
Con guration Display Graphic LC display with backlight and status LED
Circuit type two-stage, transformerless (no galvanic isolation)
Data logger
Data logger for energy yield, peak output and operating duration for
the last 31 days, 12 months and 10 years
Leakage current
monitoring
Internal, AC/DC sensitive
Casing Aluminium, cover powder-coated
Surge arrester DC Requirement class D (VDE 0675-6) and/or type 3 (EN 61643-11)
Surge arrester AC Requirement class D (VDE 0675-6) and/or type 3 (EN 61643-11)
Standards &
guidelines
CE-compliant Yes
EMC
EN 61000-6-2 / EN 61000-6-3 / EN 61000-3-2 / EN 61000-3-3 /
EN 61000-3-11 / EN 61000-3-12
Standard / guideline
compliance
VDE-AR-N4105 / VDE0126-1-1 / CEI0-21 / DK 5940 Ed.2.2 /
RD661 / RD1699 / G83/1-1 / G59/2
1)
/ PPCGuide / C10/11 /
EN50438
2)
/ AS4777
Device safety VDE “GS - certi ed safety” compliant with 50178 / AS3100
Interfaces Data communication RS485 / Ethernet via two RJ45 sockets
Status signalling
contact
M12 connector with relay as NC contact / NO contact
Weight &
dimensions
Weight 13 kg 15 kg
Dimensions in mm
(L x H x W)
545 x 290 x 185
Warranty Standard 5 years / extension to 10, 15, 20, or 25 years possible
1) only the inverters SolarMax 4200S and SolarMax 6000S
2) Portugal
