SolaX Power X1-Fit-3.7C User Manual

Battery
Charger
EPS
(d-2)
(d-2-1)
(d-2-2)
d-2-1) Charger
Here the user can set the parameters of charger on this page, the inverter
is only compatible with lithium battery. Users can set the charge & discharge
parameters and awaken mode.
For the detailed parameters , please refer to below table.
Discharge Max Current
Charger
>Min Capacity
20%
Charger
Charge Max Current
Charger
18V
NOTE !
PleaseconrmtheInvertersettingformaximumcharge/discharge
currentiswithintherangeof batteryrated charge/dischargecurrent.
The charge current can be set for 0-20A.
The discharge current can be set for 0-20A.
d-2-2) EPS system ( For E&I Version only)
X1-Retro Fit inverter with E Version and I Version can work on the EPS mode.
EPS parameters can be set as below.
“Mute”means you can set the warning of system which has entered EPS mode.
-”No”means there will be a buzzing and it is the default value.
-”Yes”means you choose to shut down the warning function.
Besides ,if the buzzing is sharp, it means EPS output is over loads.
“Frequency “here can be set 50Hz or 60Hz please based on correlative loads.
> Mute: No
Frequency: 50Hz
EPS system
• When you want to use the EPS function, the setting of the discharge
cut voltage need to be higher than the Battery backup discharge Volt.
• The Battery backup discharge Volt is the min Voltage of the battery.
NOTE!
Reset
Reset Inv Energy
Reset Meter Energy
Reset Load
Reset Mgr EE
Config Guide
Reset Errorlog
(d-3)
(d-3-1)
(d-3-2)
(d-3-3)
(d-3-4)
(d-3-5)
(d-3-6)
d-3-1) Reset Inv Energy
User can reset the inverter energy record here.
Setting Setting
56 57
18V
d-3-2) Reset Errorlog
User can reset all inverter errorlog record here.
d-3-3) Reset Meter Energy
User can reset the meter energy record here.
Reset
>No<
Reset Meter Energy
Reset
>No<
Reset Inv Energy
Reset
>No<
Reset Errorlog
