Operation MethodOperation Method
b) Solar
This status shows the real time PV condition of the system, such as
input voltage, current and power situation of each PV input.
Press ”Up“ and “Down” button to review parameter, long Press “Up” to return to
Status.
Solar
U1 0.0V
I 1 0.0A
Grid
Ua
0
.0 V
Ia 0.0A
Ÿ Language
The function refers to select a language from English, German, Polish, French,
Portuguese etc.
Language
English
Ÿ Date Time
This interface is for the user to set the system date and time. Increase or
decrease the word by pressing “Up” or “Down” button. Press “Down” to confirm
and alternate to next word. After all the words are confirmed. Long press
“Down” to enter the date and time.
Date Time
>2021- 01 - 01
00:00
*
*
*
*
﹦ ﹦ ﹦ ﹦ ﹦﹦ ﹦ ﹦
﹦ ﹦ ﹦ ﹦ ﹦﹦ ﹦ ﹦
﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦
German
* Password
The default password is “2014” for the installer, which only allows the installer
to review and modify necessary settings complying to the local rules and
regulations. If further advanced setting is required, please contact the
distributor or us for assistance. We need to increase or decrease the word by
pressing up or down button. Press “Down” to confirm an alternate to the next
word. After word is confirmed, long press “Down” to enter password.
Ÿ Settings
Setting function is used for setting the inverter for safety, connection, Grid
and so on.
Settings
Safety
Export Control
Password
0 0 0 0
Safety
country
VDE4105
When inputting the password, the information of the LCD interface is shown
as below.
a) Safety
The user can set the safety standard here according to different countries
and grid tied standards. There are several standards for choice (May change
without notice). In addition, the user has an “UserDefined” option which
allows the user to customize relevant parameters within a wider range.
﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦
﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦
﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦
﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦
44 45
