13 • Technical Data
________________________________________________________________________________________________
Indication Description Remarks
D-9 connector Profibus communication (optional)
• Profibus DPV0 and DPV1, up to 12 MBPS.
• D type 9 pin connector is applied.
• Control, monitoring and setting parameters can be
achieved via the Profibus connection.
• Setting is possible only when DPV1 is
implemented.
• Refer to section
7.7.10 page 85 for programming.
• Consult the Profibus manual (request from the
factory).
3.5 Input/Output Indication
