68 • Control Keypad
_____________________________________________________________________________________________
7.7.1 Display Mode – Page 0
% OF MOTOR FLA
XX%
Displays in MINIMIZED MODE and MAXIMIZED MODE
Display and default
values
Description
% OF MOTOR FLA
Displays operating current as a percentage of motor FLA (Full Load Ampere).
RVS-DN’s Default Display. After pressing the Mode or Select keys, a time delay
is initiated. Following the delay the LCD returns to display % OF MOTOR FLA.
AMP. VOLT
0 0
Displays the current of the motor and mains voltage.
Note:
These measurements are not shown in RVS-DN 1000V and RVS-DN 1200V
models.
MOTOR INSULATION
52.8Mohm
Displays the motor winding insulation level (displays only if the optional motor
insulation card is installed).
THERMISTOR RES.
3.1 Kohm
Displays the resistance level of the motor’s thermistor (displays only if the
optional analog card is installed).
OPTION CARD
NOT INSTALLED
Displays only if there is no motor insulation or analog option card installed in the
RVS-DN.
Note:
This ignores the communication cards. Even if a communication card is installed
this message can display.
Note:
In this page parameters cannot be programmed.
