7.7 Overview of All Mode Pages and Factory Defaults
Appears only in
MAXIMIZED MODE
(1)
% OF MOTOR FLA
XX%
MAIN PARAMETERS
- **** -
START PARAMETERS
- **** -
STOP PARAMETERS
- **** -
DUAL ADJUSTMENT
PARAMETERS
Display and default
values
Display and default
values
Display and default
values
Display and default
values
Display and default
values
% OF MOTOR FLA STARTER FLC
58 AMP.
SOFT START CURVE
0(STANDARD)
SOFT STOP CURVE
0(STANDARD)
DA: INIT. VOLT.
30%
AMP. VOLT
0 0
MOTOR FLA
58 AMP.
START TACHO. GAIN
0(MIN. GAIN)
STOP TACHO. GAIN
0(MIN. GAIN)
DA: INIT. CURRENT
100%
MOTOR INSULATION
52.8Mohm
CONNECTION TYPE
LINE
PULSE TIME
0 SEC.
DEC. TIME
10 SEC.
DA: CUR. LIMIT
400% OF FLA
THERMISTOR RES.
3.1 Kohm
UNDERCURR. TRIP
0% OF FLA
INITIAL VOLTAGE
30 %
FINAL TORQUE
0 (MIN.)
DA: ACC. TIME
10 SEC.
OPTION CARD
NOT INSTALLED
UNDERCURR. DELAY
10 SEC.
INITIAL CURRENT
100 %
STORE ENABLE
STOP PARAMETERS
DA: DEC. TIME
10 SEC.
O/C – SHEAR PIN
850% OF FLA
CURRENT LIMIT
400% OF FLA
DA: MOTOR FLA
31 AMP.
O/C DELAY
0.5 SEC.
ACC. TIME
10 SEC.
STORE ENABLE
D. ADJ. PARAMETERS
OVERLOAD TRIP
115% OF FLA
MAX. START TIME
30 SEC.
OVERLOAD DELAY
4 SEC – AT 5 FLA
NUMBER OF STARTS
10
UNDERVOLT. TRIP
300 VOLT
(2)
STARTS PERIOD
30 MIN.
UNDERVOLT. DELAY
5 SEC.
START INHIBIT
15 MIN.
OVERVOLT. TRIP
480 VOLT
(2)
RUN CONTACT DEL.
5 sec.
OVEERVOLT. DELAY
2 SEC.
STORE ENABLE
START PARAMETERS
STORE ENABLE
MAIN PARAMETERS
(1)
- Refer to section 6.5.1 on page 56 for changing mode from MINIMIZED MODE to MAXIMIZED MODE.
(2)
– Under/Over voltage protection default settings are as follows:
Default Setting
Rated Voltage
[V]
UNDER VOLT. TRIP
[V]
OVER VOLT. TRIP
[V]
400 300 480
480 360 576
600 450 720
690 516 750
1000 750 1200
1200 900 1440
