SECTION 3
HOOK UP _______________________________________________________
Figure 3A
Figure 3B
Figure 3C
Process Fluid Supply
(¼" push push-in-fittings)
Fill Cap
Display Screen
Controller Input Buttons
Power Inlet Module
IEC 320 power inlet module with two 5X20 fuses
Optional 5-micron particle filter
Fasten the filter-mounting bracket
via the four screws located here
On/Off Switch
