SECTION 5
OPERATION _____________________________________________________
ThermoCube II is operated via the control panel located on the front
panel. The control panel has a 8x2 character LCD display and four
input keys: UP, DOWN, ENTER, and START/STOP. These keys
work as follows:
Key
Action
UP
Pressing the UP key raises the parameter value displayed.
DOWN
Pressing the DOWN key lowers the parameter value displayed
ENTER
Pressing the ENTER key momentarily enters the parameter changed.
ENTER
Pressing and holding the ENTER key for 3 seconds causes the chiller to change the
display menu (see menu structure)
START/STOP
Pressing the START/STOP key turns on temperature control.
START/STOP
Pressing the START/STOP key while the chiller is operating turns off temperature
control (Operating Mode = *).
5.1 SIMPLE OPERATION
The ThermoCube II comes with preset operating parameters that will
work well for most applications. Once the tank is filled, follow the
steps below to operate:
1) Turn on the ThermoCube II and wait for display to read TEMP.
2) Press the UP or DOWN keys to change SETTEMP to the desired
set point.
3) Press ENTER to accept the value.
4) Press the START/STOP key to begin controlling to the
temperature just entered (SETTEMP1). The Operating Mode will
now show “C” (cooling) or “H” (heating).
5) Pressing START/STOP while the unit is controlling temperature
will stop temperature control. The Operating Mode will now show
“*” for Standby (not controlling).
Caution: Do not externally shut off the flow of coolant for more than
a ten second period; pump damage will result if run deadheaded for
extended periods of time.
The ThermoCube II will now control to the set point temperature. To
change the set point temperatures just press the UP or DOWN keys
again to change SETTEMP to the new set point, followed by ENTER.
If the Operating Mode shows “*”, press START/STOP to begin
controlling.
