THERMOCUBE II 200-650W THERMOELECTRIC CHILLER MANUAL 52-14790-1
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590 13
TELEPHONE: (845) 296-1300, FAX: (845) 296-1303, WEB: WWW.SSCOOLING.COM VERSION M2
SECTION 4
START UP ______________________________________________________
Note: In order to avoid injury or damage, operators must only use this product in the
manner specified below.
Start-up the ThermoCube II using the following steps:
1) Connect coolant tubing to fluid connections located on the left
side of the unit, labeled Process Out (supply) and Process In
(return).
2) Connect Alarm Signal connector (if option chosen).
3) Remove the reservoir cap on top and fill the reservoir to just
below the bottom of its neck with coolant. Replace cap.
4) Plug line cord into 100 - 240 VAC, 50/60 Hz.
5) Turn on switch located on the left side of the unit. The front
display should read the current coolant temperature. If the front
display reads “TANK LEVEL LOW”, add more coolant to the
reservoir until the display changes to read the coolant
temperature.
Important Notes:
1) If the tank level low alarm persists, or if another alarm is
displayed, consult section 6.0 of this manual.
2) If using an alcohol/water mixture, do not exceed 25% alcohol or
the reservoir level float may not rise sufficiently when filled to
turn off the tank level low alarm.
