SECTION 7
THERMOCUBE II OPTIONS ________________________________________
7.1 THERMOCUBE II OPTIONS AND PART NUMBER / MODEL CONFIGURATOR
This page shows all ThermoCube II options so you may consider possible configurations.
CCC: Cooling Capacity Options:
T22
200 watts at setpoint = 20C with 20C ambient air
T23
300 watts at setpoint = 20C with 20C ambient air
T24
400 watts at setpoint = 20C with 20C ambient air
T25
500 watts at setpoint = 20C with 20C ambient air
T26
650 watts at setpoint = 20C with 20C ambient air
X: Power Cord Options:
0
No power cord
1
USA/Canada
2
Europe
3
Japan
4
United Kingdom
5
Israel
6
Australia
7
Korea
8
China (3 prong)
9
NEMA 6-15 208V US straight
10
NEMA L6-15 208V US twist
11
Brazil
12
India / South Africa 6A (Type D)
13
India / South Africa 15A (Type M)
XX-YY-ZZ: Other Selectable Options
(Refer to software table TBL-1331 for software version)
-R2
RS232 Interface (9600 Baud, default to HEX)
-R5
RS232 Interface (57,600 Baud, default to ASCII)
-R4
RS485 Interface
-EN
Ethernet Interface
-TT
TTL signals (same as ThermoCube I)
Cannot be combined with AA
Unit can only be configured for one of the above options
-EF
5 micron External Liquid Filter
-AF
Air Filter
-SS
Stainless Steel Tank and Plumbing
-ST
Stainless Steel Tank Only
-LT
Low Temp Operation – Set Operating and Alarm min
to-5C, T26 -10°C
-HT
High Temp Operation – Set Operating and Alarm
max to +65C
-DC
Dry Contact Alarm Signals (No AA or TT )
-AA
Audio Alarm Buzzer (No TT or DC)
-VD
Vibration Dampening material
-FM
Flow Meter 0-10 lpm
-LD
Leak Detector
-FL
Set up for Fluorinert, Galden, or Opteon, Gear
pumps only. Cannot be combined with -C or -S
-C
Copper cold plate + Tall heat sinks (T23, T24, T25)
Cannot be combined with 1D, SS or FL
-S
SS cold plate + Tall heat sinks (T23, T24, T25)
Cannot be combined with 1D, SS or FL
Note: Cooling capacity with -FL, -C, or -S option is reduced
as much as 10-15%, depending on configuration.
10-CCC-PPPP-X-FF-XX-YY-ZZ
PPPP: Pump Options:
-1D
>1 lpm @ 35 psig Diaphragm Pump
-1G
>1 lpm @ 30 psig Gear Pump
-2G
>2 lpm @ 30 psig Gear Pump
-3GXX
>3 lpm @ 30 psig Gear Pump (XX = Flow Rate
Setting, 30 = 3 lpm, 20 = 2 lpm, etc)
-3GRF
Same as -3G30 with Run/Fill Board
-5GXX
>5 lpm @ 30 psig Gear Pump (XX = Flow Rate
Setting, 50 = 5 lpm, 30 = 3 lpm, etc)
-1C
~2 lpm @ 15 psig Centrifugal Pump
-1CL
~2 lpm @ 10 psig Centrifugal Pump
FF: External Bulkhead Fitting Options
-JG
1/4” John Guest x 1/4” bulkhead
-J2
3/8” John Guest x 3/8” bulkhead
-CP
1/4” valved CPC
-AP
1/4” valved APC
-CP2
3/8” valved CPC
-CPM
1/4” Metal valved CPC
-SW
1/4” Swage bulkhead
-S2
3/8” Swage bulkhead
-FN
1/4” Female NPT bulkhead
