3.1 ELECTRICAL CONNECTIONS (SEE FIGURE 3)
Power: The ThermoCube II AC power inlet is an IEC320-C14
socket for models T22-T25 and for model T26 an IEC320-20. Plug
the line cord provided into this socket and then into the appropriate
100-240 VAC 50/60 Hz wall outlet. To ensure safe operation of the
unit, it is important to ensure that the outlet is properly grounded. A
wide variety of power cords are available to support universal power
operation:
Country / Region
T22-25 Part Number
T26 Part Number
USA/Canada
22-22333-1
22-25200-1
Europe
22-22333-2
22-25201-1
Japan
22-22333-3
22-26084-1
UK
22-22333-4
22-26098-4
Israel
22-22800-1
22-26098-5
Australia
22-23213-1
22-26098-6
Korea
22-23526-1
22-25201-1
China (3 prong)
22-23661-1
22-26098-8
NEMA 6-15 208 US Straight
16-23918-1
22-26098-9
NEMA L6-15 208 US Twist
16-23918-2
22-26098-10
Brazil
22-25122-1
India/South Africa 6A Type D
22-26025-1
N/A
India/South Africa 15A Type M
22-26025-2
Fuses:
T22-T25: 10 amp (5mm x 20mm) F10A GDB fast acting glass
Replacement Fuse: SSCS# 20-22332-10
T26: 15 amp (5mm x 20mm) F15A GDB fast acting glass
Replacement Fuse: SSCS# 20-25202-15
RS-232: ThermoCube II comes with RS-232 communications
standard. Connections are made via a 9-pin dsub connector (see
section 7 for wiring and communications details).
RS-485: ThermoCube II comes with a RS-485 communications
option. Connections are made via a 9-pin dsub connector (see
section 7 for wiring and communications details).
Ethernet: ThermoCube II comes with an Ethernet communications
option via a standard RJ-45 jack (see section 7 for details).
Dry Contact Alarms: ThermoCube II comes with two optional dry
Contact alarms. See section 7 for details.
3.2 PLUMBING CONNECTIONS (SEE FIGURE 3)
The standard process fluid inlet (coolant return) and outlet (coolant
supply) connections, located on the left side, are 1/4” John Guest
“push in” style fittings. See figure 4 for directions on using John Guest
fittings. Other fitting options are available (see section 7).
Important Note: The ThermoCube II chiller should be located at
approximately the same level or above the system it is cooling to
avoid coolant draining back into the tank and overflowing after the
ThermoCube is turned off.
WARNING
Electrical Shock
Hazard: Never Plug
in a Line Cord with
Wet Hands
