Mode 3: Backup Mode Logic(Keep the Battery at a certain SOC and only use it
during power outage)
Backup Mode Logic: Keep the Battery at a certain SOC and only use it during power
outage.
Backup SOC Setting Range: From Battery “Overdischarge SOC” to 100%
PV Power Using Priority: Battery>Load>Grid
Load Support Priority: PV>Grid>Battery
Battery Charging Power comes from PV. (If “Charging From Grid” is allowed, it can also
come from Grid)
* The “Backup Mode” is not applicable for Lead-acid batteries.
Charging from gird for Backup mode
Path: Advanced Settings->Storage Energy Set->Storage Mode Select->Backup Mode->
ON->Backup SOC->Charging from gird for Backup mode
Settings
Charging from gird for Backup mode
2015-02-23 19 35
Allow
Not Allow
Y E S =< E N T > N O = < E S C >
Mode 2: Feed In Priority Mode Logic(Feed the excess PV to Grid in order to gain s
ubsidies)
PV Power Using Priority: Load>Grid>Battery
Load Support Priority: PV>Battery>Grid
Battery Charging Power comes from PV. (If “Charging From Grid” is allowed, it can also
come from Grid)
If “Time of Use” is “Run”, the logic will follow the charging/discharging settings and time
settings as defined in “Time of Use”. For those undefined period of time, it will still follow
the Feed in Priority logic.
Time of use for Feed for priority
Path: Advanced Settings->Storage Energy Set->Storage Mode Select->
Feed in Priority Mode->ON->Time of use for Feed for priority
Settings
Time of use for Feed for priority
2015-02-23 19 35
Optimal Income:
050.0V
050.0V
22:00----08:00
08:00----22:00
E S C
U P
D O W N E N T
Charge Limit:
Discharge Limit:
Charge Time:
Discharge Time:
HH MM HH MM
10:00
14:00
Total Time:
Total Time:
HH MM
N E X T =< E N T > D O N E =< E S C >
Stop
Charging from gird for Feed for priority
Path: Advanced Settings->Storage Energy Set->Storage Mode Select->
Feed in Priority Mode->ON->Charging from gird for Feed for priority
Settings
Charging from gird for Feed for priority
2015-02-23 19 35
Allow
Not Allow
Y E S =< E N T > N O = < E S C >
10. Appendix 10. Appendix

SOLIS RHI-5G Series Specifications

General

Type	Hybrid Inverter
Max DC Voltage	600 V
Max DC Input Power	6500 W
Nominal AC Output Power	5000 W
Max AC Output Power	5500 W
Number of MPPTs	2
Battery Voltage Range	40-60V
Max Charge/Discharge Current	100 A
Protection Degree	IP65
Frequency	50/60 Hz
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Model	RHI-5G
Rated Power Output	5kW
MPPT Voltage Range	90 V - 520 V
Efficiency	97.6%
Communication Interfaces	RS485, WiFi
Nominal AC Voltage	230V
