4 . Installati on
4 .3 Select a Locat i on f or t h e Invert er
Fi g u re 4 .3 R ecom m ended In st allat i on locati on s
To select a locati on f or t h e i n verter, t h e f ollow i ng cri t eri a sh ou ld be consi dered:
E xposu re t o di rect su nli g h t m ay cau se ou t pu t pow er derati ng . It i s recom m en ded to
avoi d i n st alli ng t h e i nvert er i n di rect su n li g h t .
It i s recom m en ded th at t h e i nverter i s i nst alled i n a cooler am bi en t w h i ch doesn't
exceed 1 04 F/4 0C .
4 . In stallat i on
To avoi d overh eati ng , alw ays m ak e su re t h e f low of ai r arou nd th e i nvert er i s not
block ed. A m i ni m u m clearance of 500m m sh ou ld be k ept betw een i n vert ers or
objects and 500m m clearance bet w een th e bot tom of th e m ach i ne an d th e g rou nd.
Vi si bi li ty of t h e LE D s an d LC D sh ou ld be con si dered.
A deq u ate venti lati on m u st be provi ded.
N O TE :
Not h i ng sh ou ld be stored on or placed ag ai nst th e i n vert er.
In stall vert i cally w i t h a m axi m u m i ncli ne of +/- 5 deg rees, exceedi n g th i s m ay cau se
o u tpu t pow er derati n g .
Fi g u re 4 .4 In vert er M ou n ti n g clearance
In stall o n a w all or stron g stru ctu re capable of beari ng t h e w ei g h t of t h e m ach i ne ( 2 4 k g ) .
W A R N IN G : R i s k o f f i r e
D e spi te caref u l con stru cti on , electri cal devi ces can cau se f i res.
D o n ot i n st all t h e i n vert er i n areas cont ai ni n g h i g h ly f lam m able m ateri als or
g ases.
D o n ot i n st all t h e i n verter i n poten t i ally e xplosi ve atm osph eres.
1
0
0
0
m m
500m m
500m m
500m m
500m m
