SOLIS S5-EH1P-L User Manual

6. Operation 6. Operation
.47. .48.
Figure 6.8 Information Page 4
Settings
Information
2015-02-23 19 35
4 / 4
Grid Meter
Meter Voltage：
Meter+ Current：
Meter Power：
Meter Energy：
Input Energy：
000.0V
00.00A
+000000W
0000.00kWh
E S C
U P
D O W N E N T
Output Energy：
0000.00kWh
0000.00kWh
PV Inverter Meter
Meter Voltage：
Meter+ Current：
Meter Power：
Meter Energy：
Input Energy：
000.0V
00.00A
+000000W
0000.00kWh
Output Energy：
0000.00kWh
0000.00kWh
NOTE:
Meter Power/Grid Power: Positive value indicates exporting power to the
grid, negative value indicates importing power from the grid
Charge Power: Positive value indicates charging, negative value indicates
discharging.
NOTE:
Information for "PV Inverter Meter" is only available when two Eastron
meters are used and Meter Placement is selected as "Grid+PV Meter".
Details please consult Solis service department.
Figure 6.6 Information Page 2
Information
2015-02-23 19 35
2 / 4
Total Energy：
This Year：
Last Year：
This Month：
Last Month：
Today：
Yesterday：
0000000kWh
0000000kWh
0000000kWh
0000kWh
0000kWh
0000.0kWh
00000.0kWh
E S C
U P
D O W N E N T
Inverter SN：
FFFFFFFFFFFFFFF
Device Status：
Grid Status：
Generating
OffGridMode
Battery Status：
Normal
Backup Status：
Normal
Figure 6.7 Information Page 3
Settings
Information
2015-02-23 19 35
3 / 4
BMS Information
Battery Voltage：
Battery Current：
Charge Limit：
Discharge Limit：
SOC Value：
00.00V
000.0A
000.0A
000.0A
000%
E S C
U P
D O W N E N T
SOH Value： 000%
BMS Status： Normal
Module Type：
No Battery
