SOLIS S5-EH1P-L User Manual

1.1 Product Description
Inverter x1
Back plate x1
Fastening screw x3
DC connector x2
AC grid terminal x1
.02..01.
1. Introduction 1. Introduction
1.2 Packaging
Please ensure that the following items are included in the packaging with your machine:
If anything is missing, please contact your local Solis distributor.
RJ45 connector x1
AC backup terminal x1
CAN cable x1
Battery Cable x2
Connector x1
Terminal cover x1
Rs485 Meter cable x1
(For Eastron Meter)
The Solis S5-EH1P-L Series is designed for residential hybrid systems, which can work
with batteries to optimize self-consumption. The unit can operate in both off-grid and
on-grid modes.
Figure 1.1 Front side view
Reminder light
Figure 1.2 Bottom side view
Display
Key
This manual covers the Solis S5-EH1P-L Series model listed below :
S5-EH1P3K-L, S5-EH1P3.6K-L, S5-EH1P4.6K-L, S5-EH1P5K-L, S5-EH1P6K-L
Battery Temperature Sensor x1
(Optional )
User manual x1
Manual
Eastron Meter x1
CT x1

SOLIS S5-EH1P-L Specifications

General

Brand	SOLIS
Model	S5-EH1P-L
Category	Inverter
Language	English
