SOLIS S5 Series Installation And Operation Manual

1.1 Product Description
.3..2.
WiFi/GPRS Stickx1
（Optional）
1.2 Packaging
When you receive the inverter, please ensure that all the parts listed below are included:
User manual x1
1. Introduction 1. Introduction
If anything is missing, please contact your local Solis distributor.
Solis S5 three phase inverters integrate DRM and backflow power control function, that
could suitable for smart grid requirement.
This manual covers the three phase inverter model listed below:
S5-GR3P3K, S5-GR3P4K, S5-GR3P5K, S5-GR3P6K, S5-GR3P8K, S5-GR3P9K,
S5-GR3P10K, S5-GR3P12K, S5-GR3P13K, S5-GR3P5K-LV, S5-GR3P6K-LV
The following two models are specially supplied for Belgium market:
S5-GR3P8K-BE, S5-GR3P10K-BE
AC connector x1
Figure 1.1 Front view
Fastening screw x2
Inverter x1
Back plate x1
DC connector x2
(4 pairs for S5-GR3P(12-13)K
and S5-GR3P(8-10)K-BE)
LED lights
LCD display
4 buttons
RJ45 connector x1
Figure 1.2a Bottom view (3-10)K
Manual
Figure 1.2b Bottom view (12-13)K
DC input
RS485
DC Switch
(optional)
AC output
DRM
CT/Meter
DC input
RS485
DC Switch
(optional)
AC output
DRM
CT/Meter
