SOLIS S5 Series Installation And Operation Manual

.58.
11. Appendix
.59.
Max. DC input voltage (Volts)
MPPT voltage range (Volts)
Max. input current (Amps)
MPPT number/Max input strings number
Rated grid voltage (Volts)
Rated output current (Amps)
Power Factor (at rated output power)
Operating frequency range (Hertz)
Max.efficiency
EU efficiency
Dimensions
1100
2/4
50
Rated output power (Watts)
Max. output power (Watts)
Max. apparent output power (VA)
600
10000
14.4
S5-GR3P10K-BE
THDi (at rated output power)
Start-up voltage (Volts)
180
Max short circuit input current (Amps)
Rated DC voltage (Volts)
Rated grid frequency (Hertz)
10000
10000
310W*563H*219D (mm)
17.8kg
Model
Weight
3/N/PE~230/400
>0.99 (0.8 leading - 0.8 lagging)
45...55
Max. output current (Amps)
14.4
Grid connection standardC10/11
Topology
Transformerless
Operating ambient temperature range
Ingress protection
Noise emission (typical)
Cooling concept
Max.operation altitude
<30 dBA
Natural convection
Self consumption (night)
-25℃...+60℃
Relative humidity
0~100%
Display
Communication connections
Warranty Terms
LCD, 2×20 Z.
5 Years (Extend to 20 Years)
Safety/EMC standard
IEC 62109-1/-2, EN 61000-6-1/-2/-3/-4
DC connection
AC connection
MC4 connector
Quick connection plug
32+32
40+40
98.5%
97.9%
＜1 W
<2%
160...1000
RS485, DO, DI, Optional: Wi-Fi, GPRS
10. Specifications
11.1 Grid standard selection guide
For different countries and regions, corresponding grid code needs to be selected in the
inverter LCD to meet the requirements of local network provider.
This instruction indicates how to change the grid code and what code should be selected in
different places.
This following list illustrates the grid standard options in the inverter which are subject to
change. It is for your reference only. If customer has any doubts or uncertainty, please
consult Solis service department for confirmation.
To set the correct grid code, please enter the following path:
Advanced Settings -> Password:0010 -> Select Standard
Detailed protection limits can be viewed when choosing the code.
Please select "Save&Send" to enforce the code.
NOTE:
Please check if the grid code setting comply with local requirement.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
Code in LCD
VDE4015
EN50549 PO
EN50549 NL
EN50438 L
France
C10/11
NRS097
CEI0-21
G98
G99
Country/Region
Germany
Poland
Netherland
France
Belgium
South Africa
Italy
UK
UK
Comments
For German Low Voltage Grid.
For Polish Low Voltage Grid
For Dutch Low Voltage Grid
General EN50438 Requirement.
Possible to be used in Austria, Cyprus, Finland,
Czech Republic, Slovenia, etc.
For French Low Voltage Grid
For Belgian Low Voltage Grid
For South African Low Voltage Grid
For Italian Low Voltage Grid
For UK Low Voltage Grid <16A
For UK Low Voltage Grid >16A
-
-
EIFS- SW
SwedenFor Swedish Low Voltage Grid
EN50549L
(EN50549-1)
General EN50549-1 requirement which meets
local requirements of most European countries
IP66
4000m

SOLIS S5 Series Specifications

General

Number of MPPTs	2
Output Voltage	230 V
Frequency	50/60 Hz
Max. AC Output Power	5000W
Operating Temperature Range	-25°C to +60°C
Rated AC Output Power	2.5 kW / 3 kW / 3.6 kW / 4 kW / 5 kW / 6 kW
Max. AC Output Current	21.7A
Cooling Method	Natural Convection
Humidity	0~100 %
Model	S5 Series
