Cycling Off Time (mins) Minutes 1 to 255
Operation When Door is Open Normal or Off
Door Open Response Time (secs) Seconds N/A, 1 to 255
Door Close Response Time (secs) Seconds N/A, 1 to 255
Operation When in Post Drip Down Recovery On or Off
Type of Load
Select the type of load connected to the relay.
Operation When Compressor is ON
Select the operation of the relay when the compressor is ON.
On = Relay will turn ON (if OFF) and remain ON when the compressor is ON.
Off = Relay will turn OFF (if ON) and remain OFF when the compressor is ON.
Cycling = Relay will cycle ON / OFF for the dened periods while the compressor is ON.
Heater = Relay will turn ON (if OFF) when the temperature is less than the heater cut-in value and turn OFF (if ON) when the
temperature is more than the heater cut-out value during compressor ON.
Cycling ON Time
The duration the relay will turn ON for while the compressor is ON. After this, the relay will turn OFF.
Cycling OFF Time
The duration the relay will turn OFF for while the compressor is ON. After this, the relay will turn ON.
Operation When Compressor is Off
Select the operation of the relay when the compressor is OFF.
On = Relay will turn ON (if OFF) and remain ON when the compressor is OFF.
Off = Relay will turn OFF (if ON) and remain OFF when the compressor is OFF.
Cycling = Relay will cycle ON / OFF for the dened periods while the compressor is OFF.
Heater = Relay will turn ON (if OFF) when the temperature is less than the heater cut-in value and turn OFF (if ON) when the
temperature is more than the heater cut-out value during Compressor OFF.
Cycling ON Time
The duration the relay will turn ON for while the compressor is OFF. After this, the relay will turn OFF.
Cycling OFF Time
The duration the relay will turn OFF for while the compressor is OFF. After this, the relay will turn ON.
Operation During Defrost
Select the operation of the relay during defrost mode.
ON = Relay will turn ON (if OFF) and remain ON during defrost mode.
OFF = Relay will turn OFF (if ON) and remain OFF during defrost mode.
Cycling = Relay will cycle ON / OFF for the dened periods during defrost mode.
Heater = Relay will turn ON (if OFF) when the temperature is less than the heater cut-in value and turn OFF (if ON) when the
temperature is more than the heater cut-out value during defrost.
Cycling ON Time
The duration the relay will turn ON during defrost mode. After this, the relay will turn OFF.
Cycling OFF Time
The duration the relay will turn OFF during defrost mode. After this, the relay will turn ON.
Operation When Probe#1 Faulty
Select the operation of Relay #2 when probe #1 is faulty.
ON = Relay will turn ON (if OFF) and remain ON until probe #1 fault has been xed.
OFF = Relay will turn OFF (if ON) and remain OFF until probe #1 fault has been xed.
Cycling = Relay will cycle ON / OFF for the dened periods until probe #1 fault has been xed.
Heater = Relay will turn ON (if OFF) when the temperature is less than the heater cut-in value and turn OFF (if ON) when the
temperature is more than the heater cut-out value until probe #1 fault has been xed.
On/Cycling = Relay will be ON when the compressor is ON. When the compressor is OFF, the relay will cycle ON / OFF for the
dened periods until probe #1 fault has been xed.
Same as Comp = Relay will operate the same as the compressor until probe #1 fault has been xed.
Cycling ON Time
The duration the relay will turn ON for while probe #1 is faulty. After this, the relay will turn OFF.
Cycling OFF Time
The duration the relay will turn OFF for while probe #1 is faulty. After this, the relay will turn ON.
Operation When Probe#2 Faulty
Select the operation of the relay when probe #2 is faulty.
ON = Relay will turn ON (if OFF) and remain ON until probe #2 fault has been xed.
OFF = Relay will turn OFF (if ON) and remain OFF until probe #2 fault has been xed.
Cycling = Relay will cycle ON / OFF for the dened periods until probe #2 fault has been xed.
Heater = Relay will turn ON (if OFF) when the temperature is less than the heater cut-in value and turn OFF (if ON) when the
temperature is more than the heater cut-out value until probe #2 fault has been xed.
On/Cycling = Relay will be ON when the compressor is ON. When the compressor is OFF, the relay will cycle ON / OFF for the
dened periods until probe #2 fault has been xed.
Same as Comp = Relay will operate the same as the compressor until probe #2 fault has been xed.
Cycling ON Time
The duration the relay will turn ON for while probe #2 is faulty. After this, the relay will turn OFF.
Cycling OFF Time
The duration the relay will turn OFF for while probe #2 is faulty. After this, the relay will turn ON.
Operation When Door is Open
Select the operation of the relay when a door event occurs.
Normal = Relay will ignore the door event and operate as dened with the compressor.
Off = Relay will turn OFF (if ON) and remain OFF until the door has been closed. It will then resume normal operation
depending on the FDEx2 mode.
Door Open Response Time
The minimum duration for the door to remain open before the relay will turn OFF.
Door Close Response Time
The duration for the door to remain closed before the relay will resume normal operation.
Operation When in Post Drip Down Recovery
Select the operation of the relay when the FDEx2 is in Post Drip Down Recovery mode.
ON = Relay will turn ON (if OFF) and remain ON during Post Drip Down Recovery mode.
OFF = Relay will turn OFF (if ON) and remain OFF during Post Drip Down Recovery mode.
10.3 TEMPERATURE CONTROL
DESCRIPTION UNIT RANGE
Regulation Temperature Probe Probe#1 or Probe#2
Temperature Blind Time (secs) Seconds 0 to 125
Temperature Unit °C or °F
Temperature Display Off-set Value °C / °F -10 to +10°C / -18 to +18°F
Temperature Resolution Number 0.1, 0.5, 1.0
Normal Settings
Cut-In Temp °C / °F N/A, -40 to +70°C / -40 to 158°F
Cut-out Temp °C / °F N/A, -40 to +70°C / -40 to 158°F
Set-back Settings
Cut-In Temp °C / °F N/A, -40 to +70°C / -40 to 158°F
Cut-out Temp °C / °F N/A, -40 to +70°C / -40 to 158°F
