12. ACCESSORIES
INPUT SENSORS
PRODUCT CODE PRODUCT DESCRIPTION
9TM25005BS T PROBE 5.0/0.5/16 100K BK26 C1A
9TM25010BS T PROBE 5.0/1.0/16 100K WT26 C1A
9TM25030BS T Probe 5.0/3.0/16 100K BK26 C1A
9TM25035BS T Probe 5.0/3.5/16 100K BK26 C1A
9TM25045BS T Probe 5.0/4.5/16 100K BK26 C1A
9TM26001WS T Probe 6.0/0.1/16 100K BK24 C1A
9TM26015BS T Probe 6.0/1.5/16 100K BK24 C1A
9TM26015WS T Probe 6.0/1.5/16 100K WT24 C1A
9W10120BS D SWITCH N/O SPST 2.0/BK24/C1S
9W10120WS-Y D Switch 2xN/O SPST 2.0/WT26/C1S
9W10120BX D SWITCH N/O SPST 2.0/BK24/C6S
9W10130BX D Switch N/O SPST 3.0/BK24/C6S
EXTERNAL DEVICES
PRODUCT CODE PRODUCT DESCRIPTION
92394B00 FDM4B 30mm Blue 2 Digit Display
92394R00 FDM4R 30mm Red 2 Digit Display
92394B0S FDM4B-S 30mm Blue 2 Digit Display
92394R0S FDM4R-S 30mm Red 2 Digit Display
92394W0S FDM4W-S 30mm White 2 Digit Display
92395BD0 FDM5B-D 50mm Blue 2 Digit Display
92395RD0 FDM5R-D 50mm Red 2 Digit Display
92395WD0 FDM5W-D 50mm White 2 Digit Display
92395B0S FDM5B-S 50mm Blue 2 Digit Display
92395R0S FDM5R-S 50mm Red 2 Digit Display
92395W0S FDM5W-S 50mm White 2 Digit Display
92403110 FDE - FDM4/5 Disp Cable 3.0m
9530GR10 GGR1 Remote GPS Module
8M293510 Cable 2x3 Way to uUSB RA 0.5m
8M293473 Cable 2x3 Way to uUSB RA 3m
PROGRAMMING
PRODUCT CODE PRODUCT DESCRIPTION
90500400-D SPP02D FCAX3/FCR/FCZ/FDE/FDM/FSP/FTB
8M291010 Mini USB Socket to Micro USB Plug Cable
8M293504 FDEx2 Interface Cable
13. VERSION HISTORY
VERSION
DATE COMPLETE DESCRIPTION REVIEWED BY
1.0 31/07/2019 Initial Version Anas Elhasairi
2.0 30/03/2020 Corrections & formatting Anas Elhasairi
3.0 23/12/2020 Section 4.5, 4.6, 4.9, 4.10, 8, 10 & 12 updated Anas Elhasairi
4.0 31/07/2021 Section 1.3, 3, 4.2, 7.1, 7.3, 8, 9 & 10 updated Anas Elhasairi
5.0 16/08/2021 Corrections Neville Barreto
6.0 01/06/2022 Section 1.3 updated, Document rebranded Anas Elhasairi
7.0 31/01/2023 Section 1.1, 4.7, 5, 6, 8, 10, 11 & 12 updated Richard Brown
8.0 04/05/2023 Section 10.5 updated Neville Barreto
