11. SPECIFICATION
REFRIGERATION CONTROL
Temperature Control Method Air or evaporator
Temperature Control Range -40°C to +70°C (-40°F to +158°F)
Temperature Time Delay 1 to 125 seconds
Defrost control Timed, Active or Manual (Via a display)
Advanced Defrost Mode Pre/Post Defrost, Emergency Defrost
Energy Saving Temperature Set-back, Fan Cycling
Input Type Temperature sensor & Door Switch
Temperature Probe Type 100 KΩ NTC (β
25/50
: 3990 k)
Output control Compressor, Lights, Evaporator fan, Reverse Fan, or Heater
Model Variants FDE12
Compressor Only
FDE22
Compressor & Fan
FDE32
Compressor, Fan & Aux
Relay Rating UL Rating
Compressor Relay 16 A 250 V Motor Load 240 VAC, 10 FLA, 60 LRA, 30K Cycles
Motor Load 120 VAC, 12 FLA, 72 LRA, 30K Cycles
Relay #2 5 A 250 V 5 A, 50K Resistive
Relay #3 5 A 250 V 5 A, 50K Resistive
Maximum Total Current Ranting 16 A 18 A 18 A
Intelligent Time Delay 0 to 600 seconds
Refrigerant Compatibility CO
2
& Hydrocarbon
CELLULAR CONNECTIVITY
Target Region Global
Antenna Internal
Type 2G LTE
Category EDGE, GSM, GPRS Cat-M1, Cat-NB1
Frequency Band 850 / 900 / 1800 / 1900 B1, B2, B3, B4, B5, B8, B12, B13, B18,
B19, B20, B25, B28, B39
BLUETOOTH CONNECTIVITY
Type/version BLE 4.1
RF Power Output -20 dBm to +4 dBm
Frequency 2.4 GHz ISM
Connectivity Eddystone, iBeacon & connection to the Sollatek Smart Device Application
Bluetooth Standard IEEE 802.15.1
Memory Size 32 MB for data storing between transmission
WI-FI GEO-LOCATION
Frequency Range 2.4 GHz
Protocol 802.11 b/g/n
ACCELEROMETER
Measurement Direction 3-axis
Measurement Scale ±2G / ±4G / ±8G / ±16G
BATTERY
Battery Type Rechargeable Lithium polymer
Nominal Voltage 3.7 V
Capacity 700 mAh
Typical Run Time From a Single Charge Approx. 4 months (dependant on set transmission frequency)
STATUS INDICATORS
LEDs 1 x Controller Status ; 1 x Battery Status ; 2 x GSM status
Display Connects to FDM4 & FDM5 Range
POWER & VOLTAGE PROTECTION
Nominal Voltage 115 V / 230 V
Withstand Voltage Up to 450 VAC
Working Frequency Auto-sense 45 to 60 Hz
Type of Protection High / Low voltage, Spike / Surge & Frequency
High / Low Voltage Blind time 0 to 25 sec
Surge Protection 6.5 kA, <10 ns, 160 J
Over voltage category Category II
CONNECTOR / INTERFACE
Input Connector 1 pair of 0.11” (2.80 mm) Fast-On Tabs, 1 triple 0.11” (2.80 mm) Fast-On Tabs
Output connector Up to 5 x 0.25” (6.35 mm) Fast-On Tabs (depending on model)
Data / programming Micro USB-B for Programming
External Module 6-way (2x3) Connector Block
Sim Card Push-Push Micro SIM holder
ENVIRONMENTAL
IP Rating IP20
Electronics: IP65 (PCB Encapsulated)
Operating Temperature 0°C to +45°C (32°F to +113°F)
Operating Humidity <90% RH non-condensing
Hipping/Storage Temperature -10°C to +45°C (14°F to +113°F)
CERTIFICATION / STANDARDS
Product Certication CE, IEC60730-1, IEC60730-2-9, EN60079-15, UL60730-1, UL60730-2-9
Flammability UL94 V-0 @ 1.5 mm, GWFI: 960 °C, GWIT: 850 °C
EMC Per EN 301 489-1, EN 301 489-7, EN 301 489-17
Pollution Degree 2
MECHANICAL
Mounting 4 x M4 self-tapping pozidriv screws
Unit Dimensions 112.0 x 89.0 x 31.9 mm
Unit weight 210 g
