FDEx2 INSTRUCTION MANUAL FDEx2 INSTRUCTION MANUAL
4 +44 (1753) 214 500 sollateksupport@sollatek.com 5
CONTENTS
1. INTRODUCTION 5
1.1 DESCRIPTION 5
1.2 MODEL VARIANTS 5
1.3 LED INDICATORS 6
2. FUNCTION 7
2.1 TEMPERATURE CONTROL 7
2.2 ENERGY SAVING 7
2.3 DEFROST CONTROL 7
2.4 VOLTAGE AND COMPRESSOR PROTECTION 7
3. OPERATION 8
3.1 STANDARD REGULATING MODE 8
3.2 DEFROST MODE 10
3.3 ENERGY SAVING MODE 11
4. FEATURES 12
4.1 TEMPERATURE BLIND TIME 12
4.2 BAD VOLTAGE BLIND TIME 12
4.3 TIMESAVE™ FUNCTION 13
4.4 INTELLIGENT TIME DELAY 13
4.5 CELLULAR CONNECTIVITY 14
4.6 BLUETOOTH CONNECTIVITY 14
4.7 GEO-LOCATION 14
4.8 INTERNAL RECHARGEABLE BATTERY 14
4.9 DIGITAL DISPLAY MODULE 14
5. INSTALLATION 15
5.1 FDEx2 DIMENSIONS 15
5.2 MOUNTING INSTRUCTIONS 15
5.3 INSERTING AND REMOVING THE SIM CARD 15
5.4 WIRING CONNECTIONS 16
5.5 INITIAL STARTUP 17
6. TESTING PROCEDURE 18
6.1 THERMOSTATIC FUNCTION 18
6.2 DEFROST FUNCTION 18
6.3 VOLTAGE PROTECTION FUNCTION 19
7. ALARMS & ERRORS 20
7.1 FREQUENCY MONITORING & ERROR DETECTION 20
7.2 REGULATION PROBE ERROR DETECTION 20
7.3 DEFROST PROBE ERROR DETECTION 21
7.4 INTERNAL FAULT DETECTION 21
8. CONFIGURATION 22
8.1 DESKTOP CONFIGURATION 22
8.2 REMOTE CONFIGURATION 24
9. PROGRAMMING 25
10. PARAMETERS 27
10.1 HARDWARE CONFIGURATION 27
10.2 RELAY CONFIGURATION (RELAY #2/#3) 27
10.3 TEMPERATURE CONTROL 29
10.4 ENERGY SAVING (TEMPERATURE SET-BACK) 30
10.5 DELAYS AND TIMERS 31
10.6 DEFROST FUNCTION 32
10.7 VOLTAGE PROTECTION 35
10.8 DOOR SWITCH OPERATION 35
10.9 HEATER FUNCTION 36
10.10 PROBE FAULT DETECTION (PROBE #1/#2) 36
10.11 TRANSMISSION AND GEO-LOCATION 37
11. SPECIFICATION 38
12. ACCESSORIES 40
13. VERSION HISTORY 41
1. INTRODUCTION
1.1 DESCRIPTION
The FDEx2 is a connected electronic refrigeration controller / Energy Management Device (EMD) designed to provide precise
and efficient refrigeration control for up to 3 outputs using up to 3 inputs (temperature sensors and/or door switch).
The FDEx2 provides always-on connectivity via cellular networks. Controller telemetry and performance data are sent to the
portal, which can be accessed on all devices with an internet connection. Wi-Fi sniffing provides precise asset tracking within
indoor/urban environments. The Internal battery allows the FDEx2 to transmit location data even in the event there is no mains
power.
The FDEx2 has internal Bluetooth allowing remote access via the Smart Device App to authorized service personnel to access
controller data logs and control parameters. BLE also transmits Eddystone and iBeacon for proximity marketing (nearby
customer engagement).
The FDEx2 is built to last, meeting industry benchmarks and offering voltage protection to all connected outputs. A compact
all-in-one design allows installation even when space is tight.
DEVICE OVERVIEW
1 Mains and Output Connectors
2 Temperature/door Sensor Connector
3 Temperature Sensor Connector
4 Program/door Sensor Connector
5 External Module
6 LED Status Indicators
7 SIM Card Slot
1.2 MODEL VARIANTS
The “x” in the part number FDEx2 indicates the number of controllable outputs. There are two models available:
FDE22 = 2 relays, 16 Amp compressor + 5 Amp
FDE32 = 3 relays, 16 Amp compressor + 2x 5 Amp
