FCAx3 USER MANUAL
sollateksupport@sollatek.com 25
9. PROGRAMMING
FCAx3 firmware and configuration can be updated via the Sollatek Product
Programmer device (SPP02).
The SPP02 can be programmed directly from the controller configuration
software or the SPP visual programmer (refer to SPP Visual Programmer User
Instructions for details on this method) and then uploaded to the FCAx3.
PROGRAMMING THE SPP02
There are two ways of programming the SPP02 from the Controller Desktop Interface.
• From the main menu - for quick programming with an existing configuration file.
• From the parameter configuration window - for programming when you have made changes/checked the configuration.
Downloading Parameters from the Home window.
1. Open the desktop interface on your PC.
2. Plug the SPP02 into the USB port on your PC.
3. Click Tools > Program. Select a recently saved configuration or alternatively click Browse to search for the required
configuration file.
4. If the file is selected from the recent configuration window, then click proceed to start uploading, alternatively select a file
from the file window then programming will automatically start when you open the file.
5. During the programming of the SPP02, the green LED labelled
on the SPP02 will light up and remain on as the data is
being downloaded.
6. On successful downloading, the green LED will start flashing and then turn OFF. A success message will also appear on
the screen. Click OK to close the message box. The SPP02 can now be removed from the computer.
