FCAx3 USER MANUAL
A3+ CMYK
36 +44 (1753) 214 500
Normal = The compressor ignores the door event and resumes normal operation.
OFF = The compressor will turn OFF and remain OFF during a door open event. When the door is closed, the compressor will
resume normal operation.
Door Switch Open Persistence Duration
The duration that the door remains open before the compressor will switch OFF. If the door is open for less than the set
value, the compressor will resume normal operation.
Door Switch Close Persistence Duration
The duration for the door to remain closed after a door open event before the compressor will turn back ON.
10.9 HEATER FUNCTION
DESCRIPTION UNIT RANGE
Heater Cut-In Temperature °C / °F N/A, -40 to +45°C / -40 to 113°F
Heater Cut-Out Temperature °C / °F N/A, -40 to +45°C / -40 to 113°F
Enable Other Aux Always On When Heater is On Yes or No
Note: The heater function will only be enabled if Relay #2 or #3 is congured to operate in heater mode during any of their
operation modes (operation when compressor is cycling on/ operation when compressor is cycling off/ operation during
defrost/ operation when probe#1 is faulty/ operation when probe#2 is faulty/ is set to “heater”).
Heater Cut-in Temperature
The temperature at which the heater will turn ON. If the temperature is below this value, the heater will remain OFF.
Heater Cut-Out Temperature
The temperature at which the heater will turn OFF. The heater will remain ON until the temperature reaches the Cut-Out
temperature.
Enable Other Aux Always On When Heater is On
Select whether the other connected output will always be ON when the heater relay is ON.
No = Output will resume normal operation based on set parameters (relay conguration).
Yes = Output will turn ON and remain ON while the heater is ON.
10.10 PROBE FAULT DETECTION (PROBE #1/#2/#3)
DESCRIPTION UNIT RANGE
Enable Faulty Temperature Probe Detection Yes or No
Type of Fault Detection Active or Passive
Probe Active Fault Detection Compressor Off or Cycle
Compressor Cycling On Time Minutes 1 to 255
Compressor Cycling Off Time Minutes 1 to 255
Enable Faulty Temperature Probe Detection
Select whether the FCAx3 detects for probe fault.
No = Probe fault detection disabled. FCAx3 will operate according to normal settings.
Yes = Probe fault detection enabled. FCAx3 will act according to set parameters.
Type of Fault Detection
Select the compressor operation when a fault is detected.
Active = The compressor will operate according to set parameters.
Passive = Fault will be indicated through the LED. FCAx3 will operate according to normal settings.
Probe Active Fault Detection
Select the compressor operation during an Active Fault Detection.
Compressor OFF = Compressor will turn OFF (if ON) and remain OFF until the probe fault has been xed.
Compressor Cycle = Compressor will cycle ON and OFF for dened periods to maintain cooling.
