10. PARAMETERS
10.1 HARDWARE CONFIGURATION
DESCRIPTION UNIT RANGE
Number of Outputs Number 1, 2 or 3
Number of Temperature Probes Number 1, 2 or 3
Enable Door Switch Yes or No
Number of Outputs
Select the number of connected outputs.
1 = Compressor
2 = Compressor + Aux 1
3 = Compressor + Aux 1 + Aux 2
Number of Temperature Probes
Select the number of connected temperature probes.
1 = Connect regulating probe to P1.
2 = Connect regulating probe to P1 and probe to P2.
3 = Connect regulating probe to P1 a probe to P2 and a probe to D-Sw.
Note: If three probes are required, the door switch should be disabled.
Enable Door Switch
Select whether a door switch is connected (the door switch should be tted to P2).
No = Door switch is disabled.
Yes = Door switch is enabled. You will now be able to set compressor actions based on a door event. Probe #3 will become de-
active.
10.2 RELAY CONFIGURATION (RELAY #2/#3)
DESCRIPTION UNIT RANGE
Type of Load Compressor, Evap Fan, Cond Fan, Light, Heater, Other
Operation When Compressor is On On, Off, Cycling, Heater, Light Control
Cycling On Time (mins) Minutes 1 to 255
Cycling Off Time (mins) Minutes 1 to 255
Operation When Compressor is Off On, Off, Cycling, Heater, Light Control
Cycling On Time (mins) Minutes 1 to 255
Cycling Off Time (mins) Minutes 1 to 255
Operation During Defrost On, Off, Cycling, Heater, Light Control
Cycling On Time (mins) Minutes 1 to 255
Cycling Off Time (mins) Minutes 1 to 255
Operation When Probe#1 if Faulty
On, Off, Cycling, Heater, On/Cycling, Same as
Comp, Light Control
Cycling On Time (mins) Minutes 1 to 255
Cycling Off Time (mins) Minutes 1 to 255
Operation When Probe#2 if Faulty
On, Off, Cycling, Heater, On/Cycling, Same as
Comp, Light Control
Cycling On Time (mins) Minutes 1 to 255
Cycling Off Time (mins) Minutes 1 to 255
Operation When Probe#3 if Faulty
On, Off, Cycling, Heater, On/Cycling, Same as
Comp, Light Control
Cycling On Time (mins) Minutes 1 to 255
