58
S1 User Handbook
8
SERIAL COMMUNICATION PROTOCOL
SERIAL COMMUNICATION PROTOCOL
Command Description Response
DIM:a Congure whether a channel with control ACK:
room mute selected should dim or mute
monitors when it has PFL selected
A = DIM / MUTE
1 = Dim Monitors on PFL
0 = Mute Monitors on PFL
N.B Monitors will always mute when a channel with mute enabled
goes live (ON & Fader Up) ACK:
DIM:? Read DIM / MUTE on PFL Status DIM:a,b
B = Mute Status
0 = Not Muting
1 = Muting
DIS:? Read Digital Input Status DIS:a,b,c,d
A = Channel 9 SPDIF / Optical Selection
1 = SPDIF
0 = Optical
B = Channel 9 Sync
0 = No Sync
1 = Sync
A = Channel 10 SPDIF / Optical Selection
1 = SPDIF
0 = Optical
B = Channel 10 Sync
0 = No Sync
1 = Sync
DST: Upload Sub Processor Firmware
DWN: Upload Processor Firmware
EEP:a,b Save Conguration ACK:
A = Enable write
1 = any cong updates will be written to eeprom
0 = cong updates will not be written to eeprom
B = Enable Auto Save Settings
1 = Auto save desk state enabled
0 = Disabled
EEP:? Read EEPROM Status EEP:a,b,c
C = EEPROM Auto Save Error
GPI:a,b Congure GPIO
A = GPIO Pin Number ( 1 – 5)
B = Data ACK:
