S1 User Handbook
59
8
SERIAL COMMUNICATION PROTOCOL
SERIAL COMMUNICATION PROTOCOL
Command Description Response
GPI:? Read GPIO Data GPI:X,Y
X = GPIO Cong Data
Y = GPI Register Control Data
GTB:a,b,c Congure Global Talkback Mode ACK:
A = Channel number.
1 = Ch 1
2 = selects Ch 2
etc
a = selects Ch 10
B = Input 1 Global Talkback Enable
1 = on
0 = o
C = Input 2 Global Talkback Enable
1 = on
0 = o
GTB:a? Read Global Talkback Mode Status GTB:a,b,c
A = Channel number. (see above)
MCH:a,b,c Congure Control Room Mute ACK:
A = Channel number.
1 = Ch 1
2 = selects Ch 2
etc
a = selects Ch 10
B = Input 1 Mute
1 = Mute Enabled
0 = Mute Disabled
C = Input 2 Mute
1 = Mute Enabled
0 = Mute Disabled
MCH:a? Read Control Room Mute Status MCH:a,b,c
A = Channel number. (see above)
MFM:a,||b Congure Meter Follows Monitors
A = Button Control
1 = on
0 = o
B = Lock Out Button
1 = Lock out
0 = Normal Operation ACK:
