S1 User Handbook
8
SERIAL COMMUNICATION PROTOCOL
SERIAL COMMUNICATION PROTOCOL
Command Description Response
MFM:? Read MFM Button Status MFM:a,b
MON:a,b,||c,d Congure Monitor Selection Buttons ACK:
A = Monitor Selection number.
1 selects PGM
2 selects Aux1
3 selects Aux2
4 selects Ext1
5 selects Ext2
B = Button Control
1 = on
0 = o
C = Lock Out Button
1 = Lock out
0 = Normal Operation
D = Interlock or Mix
0 = Source will Mix
1 = Source is Interlocking
MON:a? Read Monitor Selection Button Status MON:a,b,c,d
A = Channel number. (see above)
MTR:a,||b Congure Meter Mode ACK:
A = Meter Mode
2 = No Change
1= PPM
0 = VU
B = Intensity
0 = Meter Disabled
1 – 7 = Intensity Levels
8 = No Change
MTR:? Read Meter Status MTR:a,b
OPM:a Congure Digital Synchronisation ACK:
a = Mode
0 = Internal
1 = External
2 = External with fallback to internal
