SERIAL COMMUNICATION PROTOCOL
SERIAL COMMUNICATION PROTOCOL
Command Description Response
OPM:? Read Digital Sync Mode Status OPM:a,b
B = Output Sync Status
0 = No Sync
1 = Sync
OPS:x Congure Internal Operating Frequency of Digital Output
X = Frequency
0 = 32kHz
1 = 44.1kHz
2 = 48kHz
3 = Reserved
4 = 64kHz
5 = 88.2kHz
6 = 96kHz
N.B. This command is only valid when Digital sync is set to Internal
If Sync is not set to Internal, Err:07 shall be returned ACK:
OPS:? Read Internal SYNC Frequency OPS:x
If Sync is not set to Internal, Err:07 shall be returned
PFL:a,b,||c,d,e Congure CUE/PFL Buttons ACK
A = Channel number.
1 = Ch 1
2 = selects Ch 2
etc
a = selects Ch 10
B = Button Control
1 = on
0 = o
C = Auto Cancel PFL on Fader Up
1 = Auto Cancel on Fader Up
0 = Normal Operation
D = Talkback Disabled
0 = Talkback Disabled
1 = Normal Operation
E = Lock Out Button
1 = Lock out
0 = Normal Operation
N.B. Mode D is only available on Inputs 5 & 6.
If enabled the CUE/PFL Button will on ash when Input 2 is
selected. :
