SERIAL COMMUNICATION PROTOCOL
SERIAL COMMUNICATION PROTOCOL
Command Description Response
PFL:a? Read PFL Button Status PFL:a,b,c,d,e
RMA:a,b,c,d,e,f Congure Input 1 Remotes ACK:
A = Channel number.
1 = Ch 1
2 = selects Ch 2
etc
a = selects Ch 10
B = Start Function
1 = Momentary
0 = Continuous
C = Stop Function
1 = Momentary
0 = Continuous
D = Mode
0 = Remotes Disabled
1 = Start from ON & Fader Up
2 = Telco Mode (Starts on On press)
3 = Start from ON & Fader Up or CUE/PFL
4 = Telco Mode with CUE/PFL
5 = no change
E = Tally
0 = Tally Back Disabled
1 = Tally Back Enabled
F = Automation Tally (End of Track ON Button Flash Mode)
0 = Tally Disabled
1 = Tally Enabled
N.B. Channels 1-5 on Input 1 do not have stop remotes
The ‘C’ parameter must still be supplied, but will be ignored for the
mic inputs 1-5A..
If B is changed from 1 to 0, the fader may need to be cycled
before the change is made
If C = 0, it will force the channel into START/STOP mode (see CON)
If D= 2, it will force the channel into START/STOP mode (see CON)
If E=1, a GPI must be congured as a tally back for this input
(see GPI)
N.B. Tally cannot be enabled if the Remotes are not set to
TELCO mode
If F=1, a GPI must be congured as an Automation Tally Input
(see GPI)
