SONNOC SNP-LU850E - Page 65

Signal connectivity specifications
Sonnoc User Manual
65
Signal Type
Signal Format
Resolution
Aspect Ratio
V Sync (Hz)
RGB
YPbPr
PC
XGA
1024 x 768
1.33
4:3
75
V
X
85
V
X
SXGA
1152 x 864
75
V
X
1152 x 870
1.32
75
V
X
WXGA
1280 x 768
1.67
5:3
60
V
X
75
V
X
85
V
X
1280 x 800
1.6
16:10
60
V
X
75
V
X
85
V
X
SXGA
1280 x 960
1.33
4:3
60
V
X
85
V
X
1280 x 1024
1.25
5:4
60
V
X
75
V
X
85
V
X
WXGA
1360 x 768
1.78
16:9
60
V
X
1366 x 768
V
X
SXGA+
1400 x 1050
1.33
4:3
V
X
WXGA+
1440 x 900
1.6
16:10
60
V
X
75
V
X
WXGA++
1600 x 900
1.78
16:9
60
V
X
UXGA
1600 x 1200
1.33
4:3
50
V
X
60
V
X
WSXGA+
1680 x 1050
1.6
16:10
V
X
WUXGA RB
1920 x 1200RB
50
V
X
60
V
X
TV
SDTV (480i)
720 x 480
1.5
3:2
59.94
V
V
60
V
V
SDTV (576i)
720 x 576
1.25
5:4
50
V
V
EDTV (480p)
720 x 480
1.5
3:2
59.94
V
V
60
V
V
EDTV (576p)
720 x 576
1.25
5:4
50
V
V
