A6T/A6/A5 Portable Ultrasonic Diagnostic System
4701-0040-01A
4-1
4 Transducer
4.1 Use transducer
The system can support a variety of transducders for applications on body
regions such as abdominal, superficial, OB/GYN, endocavity, cardiac,
urologic and musculo-skeletal. All the transducers are broadband, with
multiple frequencies ranging from 2.0MHz to 12.0MHz. According to
advanced processing technique and precise matching with the system, the
transducers are featured with high density and high sensitivity. See Section
5.2 for detailed information on how to use the transducers.
4.2 Use biopsy guide
A biopsy switch is available for image control. Turn the switch on, and a group
of biopsy lines are activated on the screen; meanwhile, the menu will have
two additional controls for biopsy line angle and position. The suer may
confirm orientation of the biopsy line by controlling the angle and the position
of the biopsy line.
For detailed information on the installation of biopsy guide, refer to the
instruction for the biopsy guide.
