3.5 Imaging
3.5.1 Basic operation
The system supports many image modes such as B, B/B, 4B, B/M, M, and
THI. Here is the operation:

B mode press the【B】key to switch to B mode.

2B mode press the 【Dual B】key to switch to dual B mode,
the left image is alive. Press the 【Dual B】 key
again, and it alternate between left and right image.
The current live image is indicated by a triangle
below.

4B mode press the【Quad B】 key to switch to 4B mode, press
the【Quad B】key again, and it activate the upper left,
upper right, bottom left, bottom right image by turn,
The current live image is indicated by a triangle
below.

B/M mode press the【B/M mode】key to switch to B/M mode,
press the【B/M mode】key again to switch to full M
mode. The display method for M mode, B/M mode,
B/M mode can be set up in System Setting.

THI mode press the【THI】key to switch to THI (Tissue
Harmonic Imaging) mode, press THI again to exit.

Vertical invert Press the 【Up/Down】 key to invert the
current active image vertically, and the small dot
marking the image orientation is inverted as well.

Horizontal invert Press the【L/R】key to invert the current
active image horizontally, and the small dot marking
the image orientation is inverted as well.
