A6T/A6/A5 Portable Ultrasonic Diagnostic System
4701-0040-01A
3-4
The keyboard control panel is shown as below.
Fig. 3-4-1a Keyboard Control Panel
Basic functions of each key are shown in the following table.
Item English Description of Function
(1) Exam Select an exam mode for the transducer
(2) Patient Input patient information
(3) Comment Input comments
(4) File Go to disk management system
(5) Clipboard Go to clipboard function
(6) THI Tissue Harmonic Imaging
(7) Freq. Change transducer frequency
(8) Character,
number key,
Control key
Input characters or numbers; Caps Lock:
capital lock; Shift: to activate upper case
definition; Backspace: to delete characters
one by one; Clear: clear all information
