68 Installationsanleitung | Supercal 5
qp DN G PN Fig.No B (mm) H (mm) L(mm)
h
(Ø mm)
# bolts
(M)
1 m
3
/h – ¾” 16 / 25
1
125 79 110
1 m
3
/h – 1” 16 / 25 125 79 190
1,5 m
3
/h – ¾” 16 / 25 125 79 110
1,5 m
3
/h – 1” 16 / 25 125 79 190
2,5 m
3
/h – 1” 16 / 25 125 79 190
3,5 m
3
/h – 1 ¼” 16 / 25 2 78 105 260
3,5 m
3
/h 25 – 16 / 25 3 115 134 260 Ø 85 4 (M 12)
6 m
3
/h – 1 ¼” 16 / 25 2 78 105 260
6 m
3
/h 25 – 16 / 25 3 115 134 260 Ø 85 4 (M 12)
10 m
3
/h – 2” 16 / 25 2 78 122 300
10 m
3
/h 40 – 16 / 25 3 150 157 300 Ø 110 4 (M 16)
Massbilder Schwingstrahl Durchusssensor Superstatic 440
Sontex
33,44
H
47,01
L
11,37
G
53,91
B
45,85
H
111,11
L
17,91
G
33,33
B
57,44
H
111,11
L
49,14
B
Fig.1
Fig.2
Fig.3
