Sony Ericsson K850 - Appendix; Replaceable Parts

K850
1203-2528 rev. 1
APPENDIX Replaceable Parts
APPENDIX
Part List Main Board
Contains only components that are possible to replace on the main board.
Pos. number refers to the components position number on the board.
Some components are noted as MSL X. These components are moisture-sensitive and are rated at
various levels (MSL):
Level 1: Unlimited floor life; does not require dry pack or re-baking.
Level 2: 1 year floor life; </=30 C; 60%rh; shipped in dry pack; must be re-baked after
being opened if floor life is exceeded.
Level 2A: 4 week floor life; </=30 C; 60%rh; shipped in dry pack; must be re-baked after
being opened if floor life is exceeded.
Level 3: 168 hours floor life; </=30 C; 60%rh; shipped in dry pack; must be re-baked after
being opened if floor life is exceeded.
Level 4: 72 hours floor life; </=30 C; 60%rh; shipped in dry pack; must be re-baked after
being opened if floor life is exceeded.
Level 5: 48 hours floor life; </=30 C; 60%rh; shipped in dry pack; must be re-baked
after being opened if floor life is exceeded.
Level 5A: 24 hours floor life; </=30 C; 60%rh; shipped in dry pack; must be re-baked
after being opened if floor life is exceeded.
Level 6: 6 hours floor life; </=30 C; 60%rh; shipped in dry pack; must be re-baked
after being opened if floor life is exceeded.
Component placing can be found in document 1078/FEA 209 544/129.
NOTE! RF Calibration by using SERP can only be done by authorized repair centres.
Fence modification should be performed according to the Working Instruction Electrical.
Side Pos. Description Part Number Comments Page
F B2101 Osc XO 32.768 kHz LC 1200-3231 SL4 75
B C2217 Capacitor 70.0 mF 3.3 V RJE 355 1335/7 MSL1
F C3137
Capacitor Ceramic 470,0 nF +/-
10% 6,3 V K0402
RJC5163026/47 MSL1
F C3160
Capacitor Ceramic 470,0 nF +/-
10% 6,3 V K0402
RJC5163026/47 MSL1
B D2000 ASIC BB Anja 1200-0795 SL5, MSL3 75
B D2010
Mem MCP 1 Gbit + 256 Mbit
108.0 MHz 1.8 V
1200-1356 SL5 76
B D2105 IC Single bus buffer gate 1200-0425 76
B D2404 IC IF ISP1508 ES3 (3.5*3.5*0.8) 1200-1694 76
B D2420 IC IF 3.5x3.5x0.8 thin QFN 1200-1951 77
B D2460 Leveltranslator RYT109932/3 77
B E1000 Shield Can Fence 1200-2903
B E1001 Shield Can Fence 1200-2905
F E1002 Shield Can Fence 1200-2902
F L2200
Ind WW 4.7 uH +-20%
2,95x2,95x0,9
1201-2245 78
B
L2401, L2402,
L2403, L2404
Filter 0.0 Hz 0402 REG70618/20 MSL1
B N1200
Mod Radio EDGE Thor
GSM/EDGE
1203-6579
Require calibration
(SERP)
MSL R5A
Special Soldering
Process Required
- Authorized Repair
Centers Only
78
Side Pos. Description Part Number Comments Page
B N1210 Mammoth WCDMA Radio Module 1204-1670
Require calibration
(SERP)
MSL R5A
Special Soldering
Process Required
- Authorized Repair
Centers Only
79
B N1400
Module Bluetooth + FM
STLC2592
1200-6182 MSL3 79
F N2000 ASIC Vera ROP1013106/1 SL5 80
F N2201 LDO 3.0 V 150 mA CS-4 RYT113955/7 80
B N2202 IC Vreg MAX8640, 1.8V 1200-6420 81
B N2203 IC Vreg 1200-0110 81
B N2205 IC Vreg 1200-0107 82
B N2206 Voltage regulator 2,8V RYT1137822/1
B N2208
2ch-LDO, Vout1=2.8V,
Vout2=1.8V, WL-CSP6
RYT113997/4 82
B N2400 1-Bit Level Translator RYT109914/1 83
F N2402 IC ESD Prot UDFN 6 2x2 mm 1200-6309
MSL1
83
B N2500 IC Vreg 8-pin LLP 1200-2552 83
B N2525 ASIC 3-axis accelerometer 1200-1223 84
B N3100 OPAMP 1W Pb-Free RYT101947/2 84
B N3101 ASIC Tjatte3 CSP20 ROP1013074/1
MSL1
84
B N4101 IC Dri MAX8830 ES3 4x4 UCSP 1200-1922 85
F N4200 Light Sensor RKZ433938/1 85
B
S2400, S2402,
S2403
Side Push Switch 1200-2079 86
F V2202
Trans V; Dual_PMOSFET;
BYX101603_A; REQ318
RYN122910/1 86
B V2402 Diode Schottky 0,0 RKZ3236025/2
MSL1
86
B V2405
MOSFET Complementary N P 20
V (D S)
RYN901918/2 86
B V2420, V2421
Zener Diode voltage regulator
15V 5%
RKZ223905/2
MSL1
87
B V2425 Diode Protection 0.7 V SOD-882 1201-2253 87
B V2428 LED Red RKZ433924/1 87
B V2477, V2478 Diode Protection 5.0 V SOD-523 1201-0304
MSL1
87
B V2500 Trans P-ch FET WDFN6 1200-1780
MSL1
87
B X1200 Conn Antenna RPT79947 88
B
X1201, X1202,
X1203
Antenna connector SND90161 88
B X2200 Conn Leaf Spring Battery SND10622 88
F X2409, X4300 Conn BtB 22 pin RNV799045/22 89
F X2410 Conn BtB 40 pin 1200-1735 89
F X2511 Conn BtB 30 pin 1200-1733 89
B X3105 Microphone connector 1200-2112 89
F X4200 Conn BtB 26 pin 1200-0293 90
B X4301 30 Pin BtB, male, (Camera) RNV79992
SEMC Troubleshooting Manual
74 (101)
