Sony a7CII User Manual

Help Guide
Interchangeable Lens Digital Camera
ILCE-7CM2 α7CII
Focus Area Limit (still image/movie)
By limiting the types of available focus area settings in advance, you can more quickly select settings for [ Focus
Area].
Hint
When you assign [Switch Focus Area] to a desired key using [
Custom Key/Dial Set.] or [ Custom Key/Dial Set.], the focus
area changes every time you press the assigned key. By limiting the types of selectable focus areas with [
Focus Area Limit] in
advance, you can more quickly select the focus area setting you want.
Note
Types of focus areas that do not have a check mark cannot be selected using MENU or the Fn (function) menu. To select one,
add a check mark using [
Focus Area Limit].
If you remove the check mark for a focus area registered with [Switch V/H AF Area] or [AF Area Registration], the registered
settings will change.
Related Topic
Selecting the focus area (Focus Area)
Assigning frequently used functions to buttons and dials (Custom Key/Dial Set.)
TP1001166044
5-054-865-11(1) Copyright 2023 Sony Corporation
MENU →
(Focus) → [Focus Area] → [ Focus Area Limit] → Add check marks to the focus areas
that you want to use, and then select [OK].
The types of focus areas marked with
(check mark) will be available as settings.
1
170

Sony a7CII Specifications

General

Effective Megapixels	33.0 MP
ISO Sensitivity	100-51200 (expandable to 50-204800)
Autofocus System	Fast Hybrid AF (phase-detection AF / contrast-detection AF)
Image Stabilization	5-axis in-body image stabilization
Continuous Shooting	Up to 10 fps
Dimensions	124.0 x 71.1 x 63.4 mm
Image Processor	BIONZ XR
Sensor Type	Full-frame CMOS
Video Recording	4K 60p
Viewfinder	0.39-type electronic viewfinder
LCD Screen	3.0-inch vari-angle touchscreen
Connectivity	Wi-Fi, Bluetooth, USB Type-C
Weight	514 g (with battery and memory card)
Memory Card Slots	1 (SD/SDHC/SDXC, UHS-II compatible)
