Adjustment Using the Menus
63
[Closed Caption]
Sets the items for the closed caption display.
When [Format] of the [Channel Configuration] menu is
set to [Composite] or [HDMI], the closed caption
cannot be displayed.
[Audio Level Meter]
Sets the audio level meter.
When [Format] of the [Channel Configuration] menu
is set to [Composite] or [HDMI], the audio level meter
cannot be displayed.
The items selectable with [Audio CH] are different
depending on the input signal.
[Position] Sets the display position for the channel
number.
[Top Left]: top left
[Top Center]: top center
[Top Right]: top right
[Bottom Left]: bottom left
[Bottom Center]: bottom center
[Bottom Right]: bottom right
[CH Name] Sets the display mode of the channel
name.
[Auto]: Disappears after being
displayed for a while.
[Off]: Not displayed.
[Position] Sets the display position for the channel
name.
[Top Left]: top left
[Top Center]: top center
[Top Right]: top right
[Bottom Left]: bottom left
[Bottom Center]: bottom center
[Bottom Right]: bottom right
[Scan Mode] Sets the display mode of the scan mode.
[Auto]: Disappears after being
displayed for a while.
[Off]: Not displayed.
[Position] Sets the display position for the scan
mode.
[Top Left]: top left
[Top Center]: top center
[Top Right]: top right
[Bottom Left]: bottom left
[Bottom Center]: bottom center
[Bottom Right]: bottom right
Submenu Setting
[Closed Caption] Sets whether or not to display closed
caption signal ([Off] or [On]).
Submenu Setting
[Type] Sets the closed caption type.
[Auto1]: Select to set to 608(VBI)
when the SD-SDI signal is input or
708 when the HD-SDI signal is
input.
[Auto2]: Select to set to 608(VBI)
when the SD-SDI signal is input or
608(708) when the HD-SDI signal is
input.
[708]: Select to display the closed
caption signal of the EIA/CEA-708
standards.
[608(708)]: Select to display the
closed caption signal of the EIA/
CEA-608 standards transmitted by
EIA/CEA-708 standards.
[608(VBI)]: Select to display the
closed caption signal of the EIA/
CEA-608 standards transmitted by
using the line 21.
[Service 708] Sets Service when [Type] is set to [708].
You can select from [Service1] to
[Service6]. (Default value: [Service1])
[Service 608] Sets Service when [Type] is set to
[608(VBI)] or [608(708)].
You can select from [CC1] to [CC4] or
[Text1] to [Text4]. (Default value:
[CC1])
[OSD Level] Sets the luminance of the letter.
You can select from [High] (bright) or
[Low] (dark).
Submenu Setting
[Audio CH] Sets the audio channel.
When the Dual Link and 3G-B signal
is input
Select [CH1-CH8] or [CH9-CH16].
When another signal is input
[CH1-CH8] and [CH9-CH16] is set.
[Position] Sets the display position of the audio
level meter.
Select [Bottom] (lower) or [Top]
(upper).
[Transparency] Sets the background transparency of the
audio level meter.
[Black]: The background becomes
black.
[Half]: The background becomes
translucent.
Submenu Setting
