1) Also compatible with the frame rate 1/1.001.
2) For composite signals, displayed as masked when blanking
SMPTE ST170 (480/59.94i) and ITU-R BT.470 (576/50i)
horizontally.
 Over Scan: The area size where 5% over scan portion
in the normal scan is masked.
 Native Scan Aspect Correction: The area over the H
size (1920) is not displayed.
HDMI
1920 × 1080/60
1)
i
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1920 × 1080/50P
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1920 × 1080/60
1)
P
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
1280 × 720/24
1)
P 16:9 1280 × 720 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
1280 × 720/25P 16:9 1280 × 720 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
1280 × 720/30
1)
P 16:9 1280 × 720 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
1280 × 720/50P 16:9 1280 × 720 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
1280 × 720/60
1)
P 16:9 1280 × 720 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2048 × 1080/24
1)
PsF
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
2048 × 1080/24
1)
P
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
2048 × 1080/25PsF
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
2048 × 1080/25P
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
2048 × 1080/30
1)
PsF
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
2048 × 1080/30
1)
P
1.896:1
2048 × 1080
1920 × 1013 1862 × 982 1829 × 965 960 × 506
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
Signal system
Aspect
ratio
Native Scan
×1
Native Scan
×2
Native Scan
Aspect
Correction
Normal
Scan
Under Scan Over Scan Side by Side
(H) × (V)(H) × (V)(H) × (V)(H) × (V)(H) × (V)(H) × (V)(H) × (V)
Signal system
Aspect
ratio
Native Scan
×1
Native Scan
×2
Native Scan
Aspect
Correction
Normal
Scan
Under Scan Over Scan Side by Side
(H) × (V)(H) × (V)(H) × (V)(H) × (V)(H) × (V)(H) × (V)(H) × (V)
640 × 480/60
1)
P 4:3 640 × 480 1280 × 960 1280 × 960 1440 × 1080 1397 × 1048 1371 × 1029 960 × 720
720 × 480/60
1)
P
4:3
720 × 480 1440 × 960
1280 × 960 1440 × 1080 1397 × 1048 1371 × 1029 960 × 720
16:9 1707 × 960 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
1280 × 720/60
1)
P 16:9 1280 × 720 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
1920 × 1080/60
1)
i
16:9
1920 × 1080
1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
2.39:1 1920 × 803 1862 × 779 1829 × 765 960 × 402
720 (1440)
2)
× 480/60
1)
i
4:3
720 × 480 1440 × 960
1280 × 960 1440 × 1080 1397 × 1048 1371 × 1029 960 × 720
16:9 1707 × 960 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
720 × 576/50P
4:3
720 × 576 1440 × 1152
1536 × 1152 1440 × 1080 1397 × 1048 1371 × 1029 960 × 720
16:9 2048 × 1152 1920 × 1080 1862 × 1048 1829 × 1029 960 × 540
