6-3. PRINTED WIRING BOARD – BD SECTION –
• See page 15 for Circuit Boards Location.
Ref. No. Location
Semiconductor
Location
IC102 B-2
Q101 C-3
– 19 – – 20 –
CDP-CE525
Ref. No. Location
Semiconductor
Location
IC101 C-2
IC103 C-1
(Page 22)
