– 9 –
1
Flat type wire (16 core
)
(BD board, to CN101)
2
Screw
(M3x12)
3
Two screws
(PTPWH2.6x6)
4
Two screws
(PTPWH2.6x6)
5
Holder (BU)
6
Compression spring (BU)
7
Compression spring (BU)
8
Base unit (BU-5BD25)
1
Stopper washer (5)
7
Stopper washer (5)
8
Gear (U/D)
9
Five screws
(BVTP3x8)
!º
Bracket (GEAR
)
assembly
2 Gear (REV)
3 Stopper washer (5)
4 Gear (MAIN)
5 Screw
(BVTP3x8)
6 Rotary encoder
3-3. BASE UNIT
3-4. BRACKET (GEAR) ASSEMBLY
