Sony CDP-CE525 Service Manual

– 8 –
SECTION 3
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
3-1. CASE AND FRONT PANEL
3-2. BACK PANEL AND DISC TABLE
1 Connector (Power cord)
2 Six screws
(BVTP3x10)
3 Back pane
l
4 Flat type wire (6 core)
(MAIN board, to CN404)
5 Screw
(BVTP3x8)
6 Bracket (guide B1)
!™ Bracket (guide B1)
7 Screw (BVTP3x8)
9 Screw (BVTP3x8)
!¡ Screw (BVTP3x8)
!£ Screw (PTPWH3x12)
!¢ Disc table (B)
!∞ Disc table (A)
8 Bracket (guide F1)
!º Bracket (guide F1)
1 Two screws
(M3x8)
2 Two screws
(M3x8)
3 Two screws
(BV3x8)
4 Case
5 Four screws
(BVTP3x10)
6 Three screws
(BVTP3x10)
7 Bottom plate
8 Flat type wire (17 core)
(MAIN board, to CN402)
9 Flat type wire (9 core)
(MAIN board, to CN403)
!º Two screws
(BVTT3x8)
!¡ Three screws
(BVTP3x10)
!™ Front panel
