Sony CDP-CE525 Service Manual

– 49 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
R343 1-216-073-00 METAL CHIP 10K 5% 1/10W
R360 1-216-295-91 SHORT 0
R362 1-216-073-00 METAL CHIP 10K 5% 1/10W
R363 1-216-073-00 METAL CHIP 10K 5% 1/10W
R364 1-216-073-00 METAL CHIP 10K 5% 1/10W
R365 1-216-073-00 METAL CHIP 10K 5% 1/10W
R381 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R382 1-216-073-00 METAL CHIP 10K 5% 1/10W
R383 1-216-001-00 METAL CHIP 10 5% 1/10W
R403 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R404 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R405 1-216-077-00 METAL CHIP 15K 5% 1/10W
R406 1-216-077-00 METAL CHIP 15K 5% 1/10W
R407 1-216-691-11 METAL CHIP 47K 0.5% 1/10W
R408 1-216-691-11 METAL CHIP 47K 0.5% 1/10W
R409 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R410 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R411 1-216-105-91 RES,CHIP 220K 5% 1/10W
R412 1-216-047-91 RES,CHIP 820 5% 1/10W
R413 1-216-033-00 METAL CHIP 220 5% 1/10W
R414 1-216-033-00 METAL CHIP 220 5% 1/10W
R415 1-216-295-91 SHORT 0
R416 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R418 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R419 1-216-097-91 RES,CHIP 100K 5% 1/10W
R420 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R421 1-216-073-00 METAL CHIP 10K 5% 1/10W
R422 1-247-807-31 CARBON 100 5% 1/4W
R450 1-216-113-00 METAL CHIP 470K 5% 1/10W
R451 1-216-073-00 METAL CHIP 10K 5% 1/10W
R452 1-216-072-00 METAL CHIP 9.1K 5% 1/10W
R453 1-216-073-00 METAL CHIP 10K 5% 1/10W
R454 1-216-073-00 METAL CHIP 10K 5% 1/10W
R455 1-216-073-00 METAL CHIP 10K 5% 1/10W
R456 1-216-048-00 METAL CHIP 910 5% 1/10W
R457 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R470 1-216-073-00 METAL CHIP 10K 5% 1/10W
R471 1-216-073-00 METAL CHIP 10K 5% 1/10W
R503 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R504 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R505 1-216-077-00 METAL CHIP 15K 5% 1/10W
R506 1-216-077-00 METAL CHIP 15K 5% 1/10W
R507 1-216-691-11 METAL CHIP 47K 0.5% 1/10W
R508 1-216-691-11 METAL CHIP 47K 0.5% 1/10W
R509 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R510 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R511 1-216-105-91 RES,CHIP 220K 5% 1/10W
R512 1-216-047-91 RES,CHIP 820 5% 1/10W
R513 1-216-033-00 METAL CHIP 220 5% 1/10W
R514 1-216-033-00 METAL CHIP 220 5% 1/10W
R516 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R517 1-216-097-91 RES,CHIP 100K 5% 1/10W
R518 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R519 1-216-097-91 RES,CHIP 100K 5% 1/10W
R520 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R521 1-216-073-00 METAL CHIP 10K 5% 1/10W
R522 1-247-807-31 CARBON 100 5% 1/4W
R550 1-216-113-00 METAL CHIP 470K 5% 1/10W
R551 1-216-073-00 METAL CHIP 10K 5% 1/10W
R552 1-216-072-00 METAL CHIP 9.1K 5% 1/10W
R553 1-216-073-00 METAL CHIP 10K 5% 1/10W
R554 1-216-073-00 METAL CHIP 10K 5% 1/10W
R555 1-216-073-00 METAL CHIP 10K 5% 1/10W
R556 1-216-048-00 METAL CHIP 910 5% 1/10W
R557 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R601 1-216-085-00 METAL CHIP 33K 5% 1/10W
R602 1-216-073-00 METAL CHIP 10K 5% 1/10W
R603 1-216-091-00 METAL CHIP 56K 5% 1/10W
R604 1-216-073-00 METAL CHIP 10K 5% 1/10W
R607 1-216-037-00 METAL CHIP 330 5% 1/10W
R610 1-216-295-91 SHORT 0
R611 1-216-295-91 SHORT 0
< SWITCH >
S401 1-571-308-11 SWITCH, SLIDE (COMMAND MODE)
< VIBRATOR >
X301 1-579-834-11 VIBRATOR, CRYSTAL (33MHz)
X401 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
**************************************************************
* 1-665-357-11 POWER SW BOARD
**************
< CONNECTOR >
CN703 1-750-186-11 CONNECTOR, BOARD TO BOARD 6P
< RESISTOR >
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-249-419-11 CARBON 1.5K 5% 1/4W F
R703 1-249-421-11 CARBON 2.2K 5% 1/4W F
R704 1-247-843-11 CARBON 3.3K 5% 1/4W
R705 1-249-427-11 CARBON 6.8K 5% 1/4W F
R706 1-249-431-11 CARBON 15K 5% 1/4W
R707 1-249-427-11 CARBON 6.8K 5% 1/4W F
R708 1-249-421-11 CARBON 2.2K 5% 1/4W F
R709 1-247-843-11 CARBON 3.3K 5% 1/4W
< SWITCH >
S701 1-554-303-21 SWITCH, TACTILE (DISC 1)
S702 1-554-303-21 SWITCH, TACTILE (DISC 2)
S703 1-554-303-21 SWITCH, TACTILE (DISC 3)
S704 1-554-303-21 SWITCH, TACTILE (DISC 4)
S705 1-554-303-21 SWITCH, TACTILE (DISC 5)
S706 1-554-303-21 SWITCH, TACTILE (CONTINUE)
S707 1-554-303-21 SWITCH, TACTILE (SHUFFLE)
S708 1-554-303-21 SWITCH, TACTILE (PROGRAM)
S709 1-554-303-21 SWITCH, TACTILE (REPEAT)
S710 1-554-303-21 SWITCH, TACTILE (DISC CHECK)
S751 1-554-118-00 SWITCH, PUSH (1 KEY)(1/u)
**************************************************************
POWER SW
