Pin No. Pin Name I/O Pin Description
54 ILL-ON O Illumination output
55 C.ALARM I Caution alarm select input (Used/Not used)
56 NC I Not used (Connect to ground)
57 NC — Fixed at “H” in this set.
58 LCD-CE O LCD drive chip select output
59 EZ-SEL I SHIFT + input
60 SENS I Information input from servo IC.
61 FOK I Focus OK input
62 LD-ON O Laser diode control
63 NC — Not used. (Connect to ground)
64 [IN] ST/MONO I/O Used for both STEREO indicator display input and force MONO output. (FM)
[OUT] MONO
65 LCD-CKO O LCD driver serial clock output
66 LCD-So O LCD driver serial data output
67 INH O INHbit output
68 SQ-CKo O Q data read serial clock output
69 CD-RST O Servo IC/DAC reset output
70 SQ-SI I Q data input
71 CD-SO O Serial data output to servo IC.
72 CD-LAT O Data latch output to servo IC.
73 CD-CKO O Serial clock output to servo IC.
74 VREF — Not used.
75 GND1 — Ground
76 X-OUT — Crystal oscillator connection (4.5 MHz)
77 X-IN I Crystal oscillator connection (4.5 MHz)
78 BU-IN I Back-up detection
79 VDD1 — Power supply (+5 V)
80 RESET I RESET input
