– 44 –
DISCIN DISPLAY
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND : Canadian model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
Note:
When indicating parts by reference
number, please include the board
name.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
* 1-659-836-11 DISCIN BOARD
************
< SWITCH >
SW1 1-572-288-21 SWITCH, PUSH
SW2 1-572-288-21 SWITCH, PUSH
**************************************************************
* A-3294-555-A DISPLAY BOARD, COMPLETE (CDX-2250)
************************
* A-3294-636-A DISPLAY BOARD, COMPLETE (CDX-3500)
************************
3-019-558-01 SHEET (D) (LCD)
* 3-019-557-01 PLATE (LCD), GROUND
* 3-019-561-01 SHEET, LCD COLOR
* X-3376-745-1 HOLDER ASSY, LCD
< CAPACITOR >
C551 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C552 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C553 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
* CNP552 1-779-130-11 PIN, CONNECTOR 1P
< DIODE >
D551 8-719-073-15 DIODE SDZ5V1
D552 8-719-067-70 DIODE SDZ6V2-6.2
D554 8-719-068-68 DIODE SDZ6V2WA
D561 8-719-067-77 DIODE SML-010PT-T86 (SENS)
D562 8-719-067-77 DIODE SML-010PT-T86 (DSPL)
D563 8-719-067-77 DIODE SML-010PT-T86 (6)
D564 8-719-067-77 DIODE SML-010PT-T86 (1)
D565 8-719-067-77 DIODE SML-010PT-T86 (OFF)
D566 8-719-067-77 DIODE SML-010PT-T86 (SOUND)
D567 8-719-067-77 DIODE SML-010PT-T86 (SOURCE)
D568 8-719-067-77 DIODE SML-010PT-T86 (4)
D569 8-719-067-77 DIODE SML-010PT-T86 (3)
D570 8-719-067-77 DIODE SML-010PT-T86 (2)
D571 8-719-067-77 DIODE SML-010PT-T86 (6)
D572 8-719-067-77 DIODE SML-010PT-T86 (5)
D573 8-719-067-77 DIODE SML-010PT-T86
D574 8-719-067-77 DIODE SML-010PT-T86
D575 8-719-067-77 DIODE SML-010PT-T86
D576 8-719-067-77 DIODE SML-010PT-T86
D577 8-719-067-77 DIODE SML-010PT-T86
D578 8-719-067-77 DIODE SML-010PT-T86 (MODE)
< IC >
IC551 8-759-369-90 IC LC75822ED
< JUMPER RESISTOR >
JR512 1-216-296-00 SHORT 0
JR513 1-216-296-00 SHORT 0
JR514 1-216-296-00 SHORT 0
JR515 1-216-296-00 SHORT 0
JR516 1-216-296-00 SHORT 0
JR517 1-216-296-00 SHORT 0
JR518 1-216-295-00 SHORT 0
JR519 1-216-296-00 SHORT 0
JR520 1-216-296-00 SHORT 0
JR521 1-216-296-00 SHORT 0
JR522 1-216-296-00 SHORT 0
JR561 1-216-295-00 SHORT 0
< LIQUID CRYSTAL DISPLAY >
LCD551 1-803-439-21 DISPLAY PANEL, LIQUID CRYSTAL
< PILOT LAMP >
PL551 1-517-665-21 LAMP PILOT
PL552 1-517-665-21 LAMP PILOT
< RESISTOR >
R551 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R552 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R553 1-216-206-00 RES,CHIP 2.2K 5% 1/8W
R554 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R555 1-216-210-00 RES,CHIP 3.3K 5% 1/8W
R556 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R557 1-216-218-00 RES,CHIP 6.8K 5% 1/8W
R558 1-216-073-00 METAL CHIP 10K 5% 1/10W
R559 1-216-226-00 RES,CHIP 15K 5% 1/8W
R561 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R562 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R563 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R564 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R565 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R566 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R567 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
