Sony CDX-2250 - Printed Wiring Boards -CD Mechanism Section

4-3. PRINTED WIRING BOARDS — CD MECHANISM SECTION —
CDX-2250/3500
Ref. No. Location
IC1 D-2
IC2 E-5
IC3 B-2
Q1 F-6
Q2 F-6
• Semiconductor
Location
Note:
• X : parts extracted from the component side.
• Y : parts extracted from the conductor side.
• b : Pattern from the side which enables seeing.
– 23 – – 24 –
